Organomation, founded in 1959, designs and manufactures high-quality nitrogen evaporators and extraction systems. Known for innovation and durability, their lab instruments are used globally for efficient sample preparation with strong customer support.

Organomation

Linde Argon for Spectrometry – Gas Cylinder

Linde Argon ≥99.998% for spectrometry, GC, and research. High-purity inert gas ensuring stable and accurate analytical measurements.

Argon for spectrometry from Linde is a high-purity inert gas with a purity of ≥ 99.998%, designed for demanding analytical and laboratory applications.Its chemical inertness and low impurity levels make it ideal for spectrometric techniques, ensuring stable and reproducible measurement conditions. Argon is commonly used as a carrier gas in gas chromatography and as a protective gas in spectroscopic material analysis.It is particularly suitable for applications where gas purity, minimal interference, and high analytical accuracy are essential.<h4>Key Features</h4><ul><li>High purity ≥ 99.998%</li><li>Chemically inert gas</li><li>Low trace impurity levels</li><li>Suitable for spectrometry and GC</li><li>Stable and reproducible performance</li><li>Colorless and odorless</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.998%</li><li>Supply form: gas cylinder</li></ul><h4>Applications</h4><ul><li>Carrier gas in gas chromatography (GC)</li><li>Protective gas for spectrometric material testing</li><li>Spectrometry (e.g., emission and mass spectrometry)</li><li>Measurement and analytical technologies</li><li>Research and development</li></ul>

Linde Argon 5.0 – Gas Cylinder

Linde Argon 5.0 for TIG, PAW, GC, and spectrometry. Ultra-high purity inert gas for sensitive materials and precision analytical applications.

Argon 5.0 from Linde is a high-purity inert gas (≥ 99.999%) designed for demanding applications where maximum purity and stability are essential.Its exceptional purity makes it ideal for welding sensitive metals such as titanium, tantalum, and zirconium, where even trace contamination can affect weld quality. Argon 5.0 is also widely used in analytical techniques, semiconductor processes, and research environments, ensuring stable and reproducible conditions.<h4>Key Features</h4><ul><li>Very high purity ≥ 99.999% (5.0 grade)</li><li>Chemically inert gas</li><li>Extremely low impurity levels</li><li>Suitable for sensitive materials and precision processes</li><li>Stable analytical and process conditions</li><li>Versatile applications (welding, analytics, research)</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.999% (5.0 grade)</li><li>Standard: ČSN EN ISO 14175</li><li>Supply form: gas cylinder<ul><li>10 L (200 bar)</li><li>20 L (200 bar)</li><li>50 L (200 bar)</li></ul></li></ul><h4>Applications</h4><ul><li>Shielding gas for TIG and PAW welding<ul><li>titanium, tantalum, zirconium and sensitive metals</li></ul></li><li>Semiconductor industry<ul><li>deposition and diffusion processes</li><li>thin film preparation</li></ul></li><li>Analytical applications<ul><li>carrier gas in gas chromatography (GC)</li><li>protective gas in spectrometric analysis</li></ul></li><li>Lighting industry<ul><li>filling gas for lamps</li></ul></li><li>Measurement technology, research and development</li></ul>

Linde Argon 6.0 – Gas Cylinder

Linde Argon 6.0 (≥99.9999%) for GC, spectrometry, and semiconductors. Ultra-high purity inert gas for the most demanding analytical applications.

Argon 6.0 from Linde is an ultra-high purity inert gas with a purity of ≥ 99.9999%, designed for the most demanding applications in analytics, semiconductor manufacturing, and research.Its extremely low level of trace impurities makes it ideal for use in gas chromatography, spectrometry, and other contamination-sensitive techniques. It ensures maximum measurement stability, minimal interference, and excellent reproducibility.Argon 6.0 is also well suited for advanced technological processes such as thin film deposition and diffusion processes, where ultra-clean protective atmospheres are required.<h4>Key Features</h4><ul><li>Ultra-high purity ≥ 99.9999% (6.0 grade)</li><li>Extremely low trace impurity levels</li><li>Chemically inert gas</li><li>Ideal for analytical and semiconductor applications</li><li>High stability and reproducibility</li><li>Suitable for the most demanding applications</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.9999% (6.0 grade)</li><li>Standard: ČSN EN ISO 14175</li><li>Supply form: gas cylinder<ul><li>10 L (200 bar)</li><li>50 L (200 bar)</li></ul></li></ul><h4>Applications</h4><ul><li>Semiconductor industry<ul><li>deposition and diffusion processes</li><li>thin film manufacturing</li></ul></li><li>Analytical applications<ul><li>carrier gas in gas chromatography (GC)</li><li>protective gas in spectrometric analysis</li></ul></li><li>Lighting industry<ul><li>filling gas for lamps</li></ul></li><li>Measurement technologies</li><li>Research and development</li></ul>

Organomation 6 Position N-EVAP Nitrogen Evaporator

Compact nitrogen evaporator for up to 6 samples with precise flow control, heated bath options, and wide sample compatibility.

The Organomation 6 Position N-EVAP is a compact and cost-effective sample concentrator designed for simultaneous evaporation of up to 6 samples. Based on the proven N-EVAP technology developed in the 1970s, it ensures reliable and reproducible solvent evaporation using nitrogen gas within a heated bath.The system supports a wide range of sample sizes – 10–30 mm OD as standard, and up to 30–56 mm OD with an optional holder. The circular rotating design allows easy front access to all samples.<h4>Key Features</h4><ul><li>Evaporation of up to 6 samples simultaneously</li><li>Adjustable nitrogen flow: 0–10 L/min</li><li>Individually adjustable needle valves for precise control</li><li>Circular rotating sample holder for easy access</li><li>Wide sample diameter range: 10–56 mm OD (with optional holder)</li><li>Stainless steel bath construction for durability</li><li>Water or dry bath configurations available</li><li>High temperature limit switch for safety</li><li>Phthalate-free silicone tubing to prevent contamination</li><li>Efficient nitrogen usage with minimal waste</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 6</li><li>Sample holder layout: Circular</li><li>Gas manifold: Single ring</li><li>Gas flow meter: 0–10 L/min</li><li>Standard sample OD: 10–30 mm</li><li>Optional sample OD: 30–56 mm</li><li>Gas input pressure: 20–30 psig</li><li>With regulator: 30–160 psig</li></ul><h4>Dimensions</h4><ul><li>Water bath: 33 × 28 × 79 cm</li><li>Dry bath: 33 × 28 × 70 cm</li><li>Reduced height: 33 × 28 × 61 cm</li></ul><h4>Needles</h4><ul><li>Length: 4 in (≈10 cm)</li><li>Gauge: 19 ga</li><li>Material: stainless steel + chrome-plated brass hub</li></ul><h4>Heating – Water Bath</h4><ul><li>Temperature range: 30–90 °C</li><li>Power: 550 W</li><li>Controller: mechanical thermostat</li><li>Accuracy: ±2 °C</li></ul><h4>Heating – Dry Bath</h4><ul><li>Temperature range: 40–130 °C</li><li>Power: 500 W</li><li>Medium: aluminum / glass beads</li><li>Accuracy: ±2 °C</li></ul>

Organomation 20 Position Auto N-EVAP Nitrogen Evaporator

The 20 Position Auto N-EVAP enables automated, safe evaporation of up to 20 samples with digital control and pneumatic sample handling.

The Organomation 20 Position Auto N-EVAP is the most advanced nitrogen evaporator developed by Organomation. It combines the classic N-EVAP system with timed automation and optional nitrogen self-generation.The instrument operates in both automatic and manual modes using an integrated pneumatic system. In automatic mode, samples are removed from the heating bath at the end of the cycle, reducing the risk of sample loss or damage.A digital control system provides precise control of gas flow and bath temperature, ensuring safe and reproducible evaporation of up to 20 samples simultaneously.<h4>Key Features</h4><ul><li>Automatic and manual operation modes</li><li>Capacity of up to 20 samples</li><li>Automatic sample removal after cycle completion</li><li>Digital control of temperature and timing</li><li>Nitrogen flow up to 25 L/min</li><li>Built-in pressure reducing regulator</li><li>Dual nitrogen filtration system</li><li>Pneumatic sample lift (gas piston)</li><li>Safety cover and circuit breaker</li><li>Precision needle valve control</li><li>Phthalate-free high-pressure tubing</li><li>Reduced risk of sample loss through automation</li></ul><h4>Available Model</h4><h5>Automatic 20 Position N-EVAP – Water Bath</h5><ul><li>Catalog number: 11220-A</li><li>Bath type: Water</li><li>Number of positions: 20</li><li>Dimensions: 49 × 46 × 92 cm</li><li>Temperature range: 30–100 °C</li><li>Total wattage: 1100 W</li></ul><h5>Standard Features</h5><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Built-in pressure reducing regulator</li><li>Dual nitrogen filters</li><li>Digital temperature controller (LED)</li><li>Electronic timer</li><li>High temperature limit switch</li><li>Safety cover</li><li>Circuit breaker</li><li>High-pressure phthalate-free tubing</li><li>Precision variable valve technology</li><li>Gas piston lift mechanism</li><li>Set of 20 needles (4" × 19 gauge)</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating on instrument and needles</li></ul><h4>Technical Specifications</h4><h4>General</h4><ul><li>Number of positions: 20</li><li>Sample holder layout: Circular</li><li>Gas manifold: Single Ring</li><li>Gas flow rate: 0–25 L/min</li><li>Sample size range: 10–30 mm OD</li><li>Nitrogen input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 19 ga (4")</li><li>Material: stainless steel with plated brass hub</li></ul><h4>Sample Lift Mechanism</h4><ul><li>Type: Gas piston</li><li>Function: automatic lifting/removal of samples</li></ul><h4>Control System</h4><ul><li>Digital temperature control (LED display)</li><li>Electronic timer for gas and heating</li></ul><h4>Heating Specifications</h4><ul><li>Model: 11196</li><li>Medium: Water</li><li>Inside dimensions: 11 × 11 × 5.5 in</li><li>Outside dimensions: 49 × 46 × 18 cm</li><li>Power: 1100 W</li><li>Temperature range: 30–100 °C</li><li>Controller: digital electronic</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator (20 L/min)</li><li>Pasteur pipette adapters</li><li>Pressure reducing regulator 0–160 psi</li><li>High temperature silicone fluid</li><li>Various needle sizes and gauges</li></ul><h4>Replacement Parts</h4><ul><li>NA1955 – Nitrogen generator</li><li>NA0603 – Needles 4" × 19 ga</li><li>NA0636 – Pasteur pipette adapter</li></ul>

Organomation 9 Position MULTIVAP Nitrogen Evaporator

The MULTIVAP 9 Position enables rapid evaporation of large-volume samples using a high-temperature dry block and efficient row-based nitrogen control.

The Organomation 9 Position MULTIVAP is a high-temperature dry block nitrogen evaporator designed for large volume sample evaporation.The system features a rectangular 3×3 gas distribution manifold and a dual post lifting assembly, allowing easy adjustment of needles or pipettes. Nitrogen is directed onto the sample surface, enabling rapid solvent evaporation and efficient sample concentration.Each row of three positions can be individually switched on/off, allowing significant nitrogen savings when processing fewer samples.The system operates with a heated aluminum dry block (30–120 °C) or as an ambient (unheated) version.<h4>Key Features</h4><ul><li>Up to 9 samples simultaneously (3×3 layout)</li><li>High-temperature dry block: 30–120 °C</li><li>Ambient (unheated) version available</li><li>Direct nitrogen delivery onto sample surface</li><li>Row-based gas control (3 samples per row)</li><li>Nitrogen flow range: 0–25 L/min</li><li>Built-in pressure regulator</li><li>Digital temperature control and timer</li><li>Dual spring hoist lifting system</li><li>Includes 50 mm OD beakers</li><li>Custom inserts available for different sample sizes</li><li>Compatible with organic solvents</li><li>Optional acid-resistant configuration</li></ul><h4>Available Models</h4><h5>9 Position MULTIVAP – Dry Block</h5><ul><li>Catalog number: 11809</li><li>Heating type: Dry block</li><li>Number of positions: 9</li><li>Dimensions: 41 × 36 × 76 cm</li><li>Temperature range: 30–120 °C</li><li>Power: 900 W</li></ul><h5>9 Position MULTIVAP – No Heating</h5><ul><li>Catalog number: 11809-O</li><li>Heating type: None</li><li>Number of positions: 9</li><li>Dimensions: 33 × 38 × 66 cm</li><li>Temperature: Ambient</li></ul><h4>Standard Features</h4><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Gas distribution manifold (3×3)</li><li>Nitrogen filter</li><li>Built-in pressure reducing regulator</li><li>Electronic timer</li><li>Digital temperature controller (LED)</li><li>Safety control cover plate</li><li>High temperature limit switch</li><li>Dual band hoist spring assembly</li><li>9 beakers (50 mm OD included)</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating</li><li>Pasteur pipette adapters instead of needles</li><li>Manifold and stand only (no heating platform)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 9</li><li>Layout: Rectangular (3×3)</li><li>Spacing: 5.87 cm</li><li>Standard vessels: 50 mm OD beakers</li><li>Optional tube range: 16–40 mm OD</li><li>Gas flow: 0–25 L/min</li><li>Flow control: per row (3 samples)</li><li>Gas input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 16 ga</li><li>Material: stainless steel</li><li>Needle guide: optional for tubes</li></ul><h4>Lift Mechanism</h4><ul><li>Type: Dual pulley &amp; band springs</li><li>Function: adjustable needle height</li></ul><h4>Heating Specifications</h4><ul><li>Model: 9156</li><li>Type: Aluminum dry block</li><li>Dimensions: 41 × 36 × 15 cm</li><li>Power: 900 W</li><li>Temperature range: 30–120 °C</li><li>Controller: digital electronic (LED)</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator</li><li>Custom inserts&nbsp;</li><li>Pasteur pipette adapters</li><li>Luer plugs</li><li>Various needle sizes and gauges</li></ul>

Organomation 30 Position MULTIVAP Nitrogen Evaporator

The MULTIVAP 30 Position enables high-throughput evaporation of up to 30 samples with a heated dry block, efficient gas control, and custom inserts.

The Organomation 30 Position MULTIVAP is a high-capacity dry block nitrogen evaporator designed for parallel evaporation of up to 30 samples.The system features a rectangular 5×6 gas distribution manifold and a dual post lifting assembly. Nitrogen is directed onto the sample surface, enabling rapid solvent evaporation and efficient concentration.Each row of 5 samples can be independently switched on/off, allowing significant nitrogen savings when processing fewer samples.The system operates with a heated aluminum dry block (30–120 °C) or as an ambient (unheated) version. Custom-made inserts and blocks ensure optimal heat transfer for specific sample sizes.<h4>Key Features</h4><ul><li>Up to 30 samples simultaneously (5×6 layout)</li><li>High-temperature dry block: 30–120 °C</li><li>Ambient (no heating) version available</li><li>Direct nitrogen blowdown onto sample surface</li><li>Row-based gas control (5 samples per row)</li><li>Nitrogen flow: 0–25 L/min</li><li>Built-in pressure regulator</li><li>Digital temperature control and timer</li><li>Dual spring hoist system</li><li>Custom inserts for optimized heat transfer</li><li>Compatible with organic solvents</li><li>Optional acid-resistant version</li></ul><h4>Available Models</h4><h5>30 Position MULTIVAP – Dry Block</h5><ul><li>Catalog number: 11830</li><li>Heating type: Dry block</li><li>Number of positions: 30</li><li>Dimensions: 41 × 36 × 76 cm</li><li>Temperature range: 30–120 °C</li><li>Power: 900 W</li></ul><h5>30 Position MULTIVAP – No Heating</h5><ul><li>Catalog number: 11830-O</li><li>Heating type: None</li><li>Number of positions: 30</li><li>Dimensions: 33 × 38 × 66 cm</li><li>Temperature: Ambient</li></ul><h4>Standard Features</h4><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Gas distribution manifold (5×6)</li><li>Nitrogen filter</li><li>Built-in pressure reducing regulator</li><li>Digital temperature controller (LED)</li><li>Electronic timer</li><li>Safety control cover plate</li><li>High temperature limit switch</li><li>Dual band hoist spring assembly</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating</li><li>Pasteur pipette adapters instead of needles</li><li>Manifold and stand only (no heating platform)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 30</li><li>Layout: Rectangular (5×6)</li><li>Spacing: 3.33 cm</li><li>Sample diameter range: 16–30 mm OD</li><li>Gas flow: 0–25 L/min</li><li>Flow control: per row (5 samples)</li><li>Gas input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 19 ga</li><li>Material: stainless steel</li><li>Needle guide: optional</li></ul><h4>Lift Mechanism</h4><ul><li>Type: Dual pulley &amp; band springs</li><li>Function: adjustable needle height</li></ul><h4>Heating Specifications</h4><ul><li>Model: 9156</li><li>Type: Aluminum dry block</li><li>Dimensions: 41 × 36 × 15 cm</li><li>Power: 900 W</li><li>Temperature range: 30–120 °C</li><li>Controller: digital electronic (LED)</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator</li><li>Custom inserts</li><li>Pasteur pipette adapters (not compatible with needle guide)</li><li>Luer plugs</li><li>Various needle sizes and gauges</li></ul>

Organomation H Series Hydrogen Generator

The H Series Hydrogen Generator delivers up to 600 mL/min hydrogen with 99.9999% purity, advanced safety features, and scalable modular design.

The Organomation H Series Hydrogen Generator is a modular hydrogen generation system designed for GC, GC-MS (GC-MSD), and FAST GC applications. It is available in three models with flow rates of 200, 400, and 600 mL/min, delivering ultra-high purity hydrogen up to 99.9999%.The system uses HT PEM electrolytic cell technology, producing hydrogen on demand, minimizing internal gas storage and enhancing safety.A comprehensive safety system includes acoustic alarms, display messages, and automatic shutdown in case of gas leaks, with automatic switching to inert gas if hydrogen production stops.The generator features a touchscreen CPU, supports CAN-BUS and LAN connectivity, and allows real-time monitoring, diagnostics, and maintenance management. Up to four units can be connected in parallel for scalable performance.<h4>Key Features</h4><ul><li>Three models: 200 / 400 / 600 mL/min</li><li>Hydrogen purity up to 99.9999% (UHP)</li><li>HT PEM electrolytic cell technology</li><li>On-demand hydrogen production</li><li>Advanced safety system with alarms and auto shutdown</li><li>Automatic switch to inert gas</li><li>Removable water tank for easy maintenance</li><li>Low maintenance and low operating cost</li><li>Parallel connection of up to 4 units</li><li>Touchscreen CPU with CAN-BUS and LAN</li><li>Full monitoring of system status and alarms</li></ul><h4>Available Models</h4><h5>H Series 200</h5><ul><li>Flow rate: 200 mL/min ±10%</li><li>Power consumption: 110 W</li></ul><h5>H Series 400</h5><ul><li>Flow rate: 400 mL/min ±10%</li><li>Power consumption: 180 W</li></ul><h5>H Series 600</h5><ul><li>Flow rate: 600 mL/min ±10%</li><li>Power consumption: 250 W</li></ul><h4>Standard Features</h4><ul><li>HT PEM electrolytic cell</li><li>Touchscreen CPU</li><li>LAN connectivity</li><li>CAN-BUS communication</li><li>Removable water tank</li><li>Automatic water refill pump</li><li>Safety system with alarms and auto shutdown</li><li>Automatic inert gas switching</li><li>Modular stackable configuration</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: HT PEM electrolytic cell</li><li>Purity: 99.9999%</li><li>Oxygen: &lt; 1 ppm</li><li>Dew point: &lt; -70°C</li><li>Output pressure: 2–8 bar (30–116 psi)</li><li>Max altitude: 2000 m</li><li>Noise: &lt; 50 dBA</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>H200: 110 W</li><li>H400: 180 W</li><li>H600: 250 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–35 °C</li><li>Humidity: max 90% non-condensing</li></ul><h4>Water Requirements</h4><ul><li>Minimum resistivity: &gt;1 MΩ·cm (ASTM II)</li><li>Recommended: &lt;10 MΩ·cm (ASTM I)</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 47 × 38 × 53 cm</li><li>Weight: 30 kg</li></ul><h4>Connections</h4><ul><li>Hydrogen output: G 1/8" female (AISI 316)</li><li>Exhaust: 4 mm quick connector</li><li>Water input: 1/4" connection</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>Water demineralizer</li><li>Maintenance kit (9,000 / 18,000 hours)</li><li>Water refill pump</li></ul>

Organomation HG 2200 R Hydrogen Generator

The Organomation HG 2200 R delivers up to 200 mL/min hydrogen with >99.999% purity, low noise, and easy maintenance for THC analyzers.

The Organomation HG 2200 R is a compact hydrogen generator designed for THC and emission monitoring analyzers. It delivers flow rates up to 200 mL/min with hydrogen purity greater than 99.999%, and oxygen content below 0.1 ppm when used with additional purifiers.The unit allows adjustable outlet pressure from 1 to 4 bar (up to 6 bar on demand) and features a removable external water tank for easy maintenance. An automatic water loading pump supports continuous operation.<h4>Key Features</h4><ul><li>Hydrogen flow up to 200 mL/min</li><li>Purity &gt;99.999% (UHP)</li><li>O₂ &lt;0.1 ppm with additional purifier</li><li>Adjustable outlet pressure: 1–4 bar (up to 6 bar)</li><li>Removable water tank for easy cleaning</li><li>Optional continuous water supply (pump)</li><li>Low noise level &lt;46 dB</li><li>Compact benchtop design</li><li>Simple operation and maintenance</li></ul><h4>Standard Features</h4><ul><li>UHP hydrogen generation (&gt;99.999%)</li><li>Pressure control via keyboard</li><li>Removable water tank</li><li>External water supply capability</li><li>Integrated dryer with molecular sieve</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: HG 2200 R</li><li>Flow rate: 200 mL/min</li><li>Purity: &gt;99.999%</li><li>Oxygen content: &lt;0.1 ppm (with purifier)</li></ul><h4>Output Pressure</h4><ul><li>Standard: 1–4 bar</li><li>Maximum: 6 bar (on request)</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>Power rating: 100 VA</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li><li>Noise level: &lt;46 dB</li></ul><h4>Water Requirements</h4><ul><li>Demineralized water ≤ 5 µS/cm (~0.2 MΩ·cm)</li></ul><h4>Consumables</h4><ul><li>Dryer with molecular sieve</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 31 × 48 × 38 cm</li><li>Weight: 20 kg</li></ul><h4>Warranty</h4><ul><li>1 year</li></ul><h4>Accessories / Options</h4><ul><li>Additional purifiers for ultra-low O₂</li><li>Water refill pump</li></ul>

Organomation NiGen Micro Nitrogen Generator

The Organomation NiGen Micro delivers up to 4 L/min nitrogen with 99.5% purity, PSA technology, and scalable modular configuration.

The Organomation NiGen Micro is a compact nitrogen generator based on PSA (Pressure Swing Adsorption) technology, designed for laboratory applications requiring a stable nitrogen supply up to 4 L/min with purity up to 99.5%.The system is designed for plug &amp; play integration with the AirComp oil-free compressor (Brezza series) and supports parallel connection of up to four units for increased capacity.It features a CPU with touchscreen display, with CAN-BUS and Ethernet connectivity, enabling real-time monitoring, diagnostics, alarm reporting, and maintenance control.<h4>Key Features</h4><ul><li>Nitrogen flow up to 4 L/min</li><li>Purity up to 99.5%</li><li>PSA technology with Fast Purity process</li><li>Rapid high-purity nitrogen generation</li><li>Plug &amp; play integration with AirComp compressor</li><li>Parallel connection of up to 4 units</li><li>Touchscreen CPU with CAN-BUS communication</li><li>Ethernet connection for PC integration</li><li>Low noise operation (&lt;50 dBA)</li><li>Compact modular design</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator (Claind Fast Purity technology)</li><li>Touchscreen CPU</li><li>CAN-BUS communication</li><li>Ethernet interface</li><li>Modular stackable configuration</li><li>Compatibility with AirComp compressor</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: NiGen Micro</li><li>Flow rate: 4 L/min</li><li>Purity: up to 99.5%</li><li>Technology: PSA (Pressure Swing Adsorption)</li></ul><h4>Output Parameters</h4><ul><li>Pressure: 0–6 bar (0–87 psi)</li><li>Dew point: &lt; -50 °C (±2 °C)</li></ul><h4>Air Input Requirements</h4><ul><li>Particles: ≤ 0.01 µm</li><li>Oil vapors: ≤ 0.01 mg/m³</li><li>Moisture: ≤ 3 °C dew point</li><li>Minimum pressure: 8 bar</li><li>Minimum flow: 18 L/min</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>Power consumption: 50 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–35 °C</li><li>Humidity: max 90% non-condensing</li><li>Max altitude: 2000 m</li></ul><h4>Noise</h4><ul><li>&lt;50 dBA (98% of operation)</li><li>&lt;60 dBA (short peaks)</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 47 × 38 × 53 cm</li><li>Weight: 28 kg</li></ul><h4>Connections</h4><ul><li>Compressed air inlet: G 1/8" female</li><li>Nitrogen outlet: G 1/8" female</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>AirComp oil-free compressor (Brezza series)</li><li>CPU interface (Brezza version)</li><li>Installation kit</li><li>Maintenance kit (8,000 / 16,000 hours)</li></ul>
