Linde Argon for Spectrometry – Gas Cylinder

Linde Argon ≥99.998% for spectrometry, GC, and research. High-purity inert gas ensuring stable and accurate analytical measurements.

Argon for spectrometry from Linde is a high-purity inert gas with a purity of ≥ 99.998%, designed for demanding analytical and laboratory applications.Its chemical inertness and low impurity levels make it ideal for spectrometric techniques, ensuring stable and reproducible measurement conditions. Argon is commonly used as a carrier gas in gas chromatography and as a protective gas in spectroscopic material analysis.It is particularly suitable for applications where gas purity, minimal interference, and high analytical accuracy are essential.<h4>Key Features</h4><ul><li>High purity ≥ 99.998%</li><li>Chemically inert gas</li><li>Low trace impurity levels</li><li>Suitable for spectrometry and GC</li><li>Stable and reproducible performance</li><li>Colorless and odorless</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.998%</li><li>Supply form: gas cylinder</li></ul><h4>Applications</h4><ul><li>Carrier gas in gas chromatography (GC)</li><li>Protective gas for spectrometric material testing</li><li>Spectrometry (e.g., emission and mass spectrometry)</li><li>Measurement and analytical technologies</li><li>Research and development</li></ul>

Linde Argon 5.0 – Gas Cylinder

Linde Argon 5.0 for TIG, PAW, GC, and spectrometry. Ultra-high purity inert gas for sensitive materials and precision analytical applications.

Argon 5.0 from Linde is a high-purity inert gas (≥ 99.999%) designed for demanding applications where maximum purity and stability are essential.Its exceptional purity makes it ideal for welding sensitive metals such as titanium, tantalum, and zirconium, where even trace contamination can affect weld quality. Argon 5.0 is also widely used in analytical techniques, semiconductor processes, and research environments, ensuring stable and reproducible conditions.<h4>Key Features</h4><ul><li>Very high purity ≥ 99.999% (5.0 grade)</li><li>Chemically inert gas</li><li>Extremely low impurity levels</li><li>Suitable for sensitive materials and precision processes</li><li>Stable analytical and process conditions</li><li>Versatile applications (welding, analytics, research)</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.999% (5.0 grade)</li><li>Standard: ČSN EN ISO 14175</li><li>Supply form: gas cylinder<ul><li>10 L (200 bar)</li><li>20 L (200 bar)</li><li>50 L (200 bar)</li></ul></li></ul><h4>Applications</h4><ul><li>Shielding gas for TIG and PAW welding<ul><li>titanium, tantalum, zirconium and sensitive metals</li></ul></li><li>Semiconductor industry<ul><li>deposition and diffusion processes</li><li>thin film preparation</li></ul></li><li>Analytical applications<ul><li>carrier gas in gas chromatography (GC)</li><li>protective gas in spectrometric analysis</li></ul></li><li>Lighting industry<ul><li>filling gas for lamps</li></ul></li><li>Measurement technology, research and development</li></ul>

Linde Argon 6.0 – Gas Cylinder

Linde Argon 6.0 (≥99.9999%) for GC, spectrometry, and semiconductors. Ultra-high purity inert gas for the most demanding analytical applications.

Argon 6.0 from Linde is an ultra-high purity inert gas with a purity of ≥ 99.9999%, designed for the most demanding applications in analytics, semiconductor manufacturing, and research.Its extremely low level of trace impurities makes it ideal for use in gas chromatography, spectrometry, and other contamination-sensitive techniques. It ensures maximum measurement stability, minimal interference, and excellent reproducibility.Argon 6.0 is also well suited for advanced technological processes such as thin film deposition and diffusion processes, where ultra-clean protective atmospheres are required.<h4>Key Features</h4><ul><li>Ultra-high purity ≥ 99.9999% (6.0 grade)</li><li>Extremely low trace impurity levels</li><li>Chemically inert gas</li><li>Ideal for analytical and semiconductor applications</li><li>High stability and reproducibility</li><li>Suitable for the most demanding applications</li></ul><h4>Technical Specifications</h4><ul><li>Gas: argon (Ar)</li><li>Purity: ≥ 99.9999% (6.0 grade)</li><li>Standard: ČSN EN ISO 14175</li><li>Supply form: gas cylinder<ul><li>10 L (200 bar)</li><li>50 L (200 bar)</li></ul></li></ul><h4>Applications</h4><ul><li>Semiconductor industry<ul><li>deposition and diffusion processes</li><li>thin film manufacturing</li></ul></li><li>Analytical applications<ul><li>carrier gas in gas chromatography (GC)</li><li>protective gas in spectrometric analysis</li></ul></li><li>Lighting industry<ul><li>filling gas for lamps</li></ul></li><li>Measurement technologies</li><li>Research and development</li></ul>

Organomation H Series Hydrogen Generator

The H Series Hydrogen Generator delivers up to 600 mL/min hydrogen with 99.9999% purity, advanced safety features, and scalable modular design.

The Organomation H Series Hydrogen Generator is a modular hydrogen generation system designed for GC, GC-MS (GC-MSD), and FAST GC applications. It is available in three models with flow rates of 200, 400, and 600 mL/min, delivering ultra-high purity hydrogen up to 99.9999%.The system uses HT PEM electrolytic cell technology, producing hydrogen on demand, minimizing internal gas storage and enhancing safety.A comprehensive safety system includes acoustic alarms, display messages, and automatic shutdown in case of gas leaks, with automatic switching to inert gas if hydrogen production stops.The generator features a touchscreen CPU, supports CAN-BUS and LAN connectivity, and allows real-time monitoring, diagnostics, and maintenance management. Up to four units can be connected in parallel for scalable performance.<h4>Key Features</h4><ul><li>Three models: 200 / 400 / 600 mL/min</li><li>Hydrogen purity up to 99.9999% (UHP)</li><li>HT PEM electrolytic cell technology</li><li>On-demand hydrogen production</li><li>Advanced safety system with alarms and auto shutdown</li><li>Automatic switch to inert gas</li><li>Removable water tank for easy maintenance</li><li>Low maintenance and low operating cost</li><li>Parallel connection of up to 4 units</li><li>Touchscreen CPU with CAN-BUS and LAN</li><li>Full monitoring of system status and alarms</li></ul><h4>Available Models</h4><h5>H Series 200</h5><ul><li>Flow rate: 200 mL/min ±10%</li><li>Power consumption: 110 W</li></ul><h5>H Series 400</h5><ul><li>Flow rate: 400 mL/min ±10%</li><li>Power consumption: 180 W</li></ul><h5>H Series 600</h5><ul><li>Flow rate: 600 mL/min ±10%</li><li>Power consumption: 250 W</li></ul><h4>Standard Features</h4><ul><li>HT PEM electrolytic cell</li><li>Touchscreen CPU</li><li>LAN connectivity</li><li>CAN-BUS communication</li><li>Removable water tank</li><li>Automatic water refill pump</li><li>Safety system with alarms and auto shutdown</li><li>Automatic inert gas switching</li><li>Modular stackable configuration</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: HT PEM electrolytic cell</li><li>Purity: 99.9999%</li><li>Oxygen: &lt; 1 ppm</li><li>Dew point: &lt; -70°C</li><li>Output pressure: 2–8 bar (30–116 psi)</li><li>Max altitude: 2000 m</li><li>Noise: &lt; 50 dBA</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>H200: 110 W</li><li>H400: 180 W</li><li>H600: 250 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–35 °C</li><li>Humidity: max 90% non-condensing</li></ul><h4>Water Requirements</h4><ul><li>Minimum resistivity: &gt;1 MΩ·cm (ASTM II)</li><li>Recommended: &lt;10 MΩ·cm (ASTM I)</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 47 × 38 × 53 cm</li><li>Weight: 30 kg</li></ul><h4>Connections</h4><ul><li>Hydrogen output: G 1/8" female (AISI 316)</li><li>Exhaust: 4 mm quick connector</li><li>Water input: 1/4" connection</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>Water demineralizer</li><li>Maintenance kit (9,000 / 18,000 hours)</li><li>Water refill pump</li></ul>

Organomation HG 2200 R Hydrogen Generator

The Organomation HG 2200 R delivers up to 200 mL/min hydrogen with >99.999% purity, low noise, and easy maintenance for THC analyzers.

The Organomation HG 2200 R is a compact hydrogen generator designed for THC and emission monitoring analyzers. It delivers flow rates up to 200 mL/min with hydrogen purity greater than 99.999%, and oxygen content below 0.1 ppm when used with additional purifiers.The unit allows adjustable outlet pressure from 1 to 4 bar (up to 6 bar on demand) and features a removable external water tank for easy maintenance. An automatic water loading pump supports continuous operation.<h4>Key Features</h4><ul><li>Hydrogen flow up to 200 mL/min</li><li>Purity &gt;99.999% (UHP)</li><li>O₂ &lt;0.1 ppm with additional purifier</li><li>Adjustable outlet pressure: 1–4 bar (up to 6 bar)</li><li>Removable water tank for easy cleaning</li><li>Optional continuous water supply (pump)</li><li>Low noise level &lt;46 dB</li><li>Compact benchtop design</li><li>Simple operation and maintenance</li></ul><h4>Standard Features</h4><ul><li>UHP hydrogen generation (&gt;99.999%)</li><li>Pressure control via keyboard</li><li>Removable water tank</li><li>External water supply capability</li><li>Integrated dryer with molecular sieve</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: HG 2200 R</li><li>Flow rate: 200 mL/min</li><li>Purity: &gt;99.999%</li><li>Oxygen content: &lt;0.1 ppm (with purifier)</li></ul><h4>Output Pressure</h4><ul><li>Standard: 1–4 bar</li><li>Maximum: 6 bar (on request)</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>Power rating: 100 VA</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li><li>Noise level: &lt;46 dB</li></ul><h4>Water Requirements</h4><ul><li>Demineralized water ≤ 5 µS/cm (~0.2 MΩ·cm)</li></ul><h4>Consumables</h4><ul><li>Dryer with molecular sieve</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 31 × 48 × 38 cm</li><li>Weight: 20 kg</li></ul><h4>Warranty</h4><ul><li>1 year</li></ul><h4>Accessories / Options</h4><ul><li>Additional purifiers for ultra-low O₂</li><li>Water refill pump</li></ul>

Organomation NiGen Micro Nitrogen Generator

The Organomation NiGen Micro delivers up to 4 L/min nitrogen with 99.5% purity, PSA technology, and scalable modular configuration.

The Organomation NiGen Micro is a compact nitrogen generator based on PSA (Pressure Swing Adsorption) technology, designed for laboratory applications requiring a stable nitrogen supply up to 4 L/min with purity up to 99.5%.The system is designed for plug &amp; play integration with the AirComp oil-free compressor (Brezza series) and supports parallel connection of up to four units for increased capacity.It features a CPU with touchscreen display, with CAN-BUS and Ethernet connectivity, enabling real-time monitoring, diagnostics, alarm reporting, and maintenance control.<h4>Key Features</h4><ul><li>Nitrogen flow up to 4 L/min</li><li>Purity up to 99.5%</li><li>PSA technology with Fast Purity process</li><li>Rapid high-purity nitrogen generation</li><li>Plug &amp; play integration with AirComp compressor</li><li>Parallel connection of up to 4 units</li><li>Touchscreen CPU with CAN-BUS communication</li><li>Ethernet connection for PC integration</li><li>Low noise operation (&lt;50 dBA)</li><li>Compact modular design</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator (Claind Fast Purity technology)</li><li>Touchscreen CPU</li><li>CAN-BUS communication</li><li>Ethernet interface</li><li>Modular stackable configuration</li><li>Compatibility with AirComp compressor</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: NiGen Micro</li><li>Flow rate: 4 L/min</li><li>Purity: up to 99.5%</li><li>Technology: PSA (Pressure Swing Adsorption)</li></ul><h4>Output Parameters</h4><ul><li>Pressure: 0–6 bar (0–87 psi)</li><li>Dew point: &lt; -50 °C (±2 °C)</li></ul><h4>Air Input Requirements</h4><ul><li>Particles: ≤ 0.01 µm</li><li>Oil vapors: ≤ 0.01 mg/m³</li><li>Moisture: ≤ 3 °C dew point</li><li>Minimum pressure: 8 bar</li><li>Minimum flow: 18 L/min</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>Power consumption: 50 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–35 °C</li><li>Humidity: max 90% non-condensing</li><li>Max altitude: 2000 m</li></ul><h4>Noise</h4><ul><li>&lt;50 dBA (98% of operation)</li><li>&lt;60 dBA (short peaks)</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 47 × 38 × 53 cm</li><li>Weight: 28 kg</li></ul><h4>Connections</h4><ul><li>Compressed air inlet: G 1/8" female</li><li>Nitrogen outlet: G 1/8" female</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>AirComp oil-free compressor (Brezza series)</li><li>CPU interface (Brezza version)</li><li>Installation kit</li><li>Maintenance kit (8,000 / 16,000 hours)</li></ul>

Organomation NITRO Nitrogen Generator

The Organomation NITRO 35/70 delivers up to 70 L/min nitrogen with 99.99% purity, PSA technology, remote monitoring, and integrated storage.

The Organomation NITRO (NiGen Nitro 35 / 70) is a high-performance nitrogen generator based on PSA technology, designed for applications requiring flow rates up to 70 L/min and purity up to 99.99%.It is available in two models:<ul><li>NITRO 35 – up to 35 L/min</li><li>NITRO 70 – up to 70 L/min</li></ul>The system delivers a dew point below -50 °C and hydrocarbon levels below 0.01 ppm, making it suitable for demanding applications such as LC/MS.An integrated 24 L internal tank ensures stable nitrogen supply and reduces downtime. The unit features a touchscreen display, supports remote access via Claind4You, and enables full system integration using MODBUS, MQTT, and HTTPS protocols.<h4>Key Features</h4><ul><li>Two models: 35 and 70 L/min</li><li>Nitrogen purity up to 99.99%</li><li>Dew point &lt; -50 °C</li><li>Hydrocarbon content &lt; 0.01 ppm</li><li>PSA (Pressure Swing Adsorption) technology</li><li>24 L internal storage tank</li><li>Touchscreen display with monitoring and alerts</li><li>Remote control via Claind4You</li><li>Integration via MODBUS, MQTT, HTTPS</li><li>Automatic operation with leak detection</li><li>Mobile design with wheels</li><li>Reliable continuous operation</li></ul><h4>Available Models</h4><h5>NITRO 35</h5><ul><li>Flow rate: up to 35 L/min</li><li>Weight: 75 kg</li></ul><h5>NITRO 70</h5><ul><li>Flow rate: up to 70 L/min</li><li>Weight: 90 kg</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator (Claind technology)</li><li>Touchscreen display</li><li>Automatic operation with alarms</li><li>Alarm logging and diagnostics</li><li>24 L internal tank</li><li>Remote access (Claind4You)</li><li>Communication protocols (MODBUS, MQTT, HTTPS)</li><li>Wheels for mobility</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: NiGen Nitro 35 / 70</li><li>Technology: PSA</li><li>Purity: up to 99.99%</li><li>Dew point: &lt; -50 °C</li><li>Hydrocarbons: &lt; 0.01 ppm</li><li>Output pressure: 0–6.5 bar (0–94 psi)</li></ul><h4>Flow Rate</h4><ul><li>NITRO 35: up to 35 L/min</li><li>NITRO 70: up to 70 L/min</li></ul><h4>Air Input Requirements</h4><ul><li>Particles: ≤ 0.01 µm</li><li>Oil: ≤ 0.01 mg/m³</li><li>Moisture: ≤ 3 °C dew point</li><li>Air flow:<ul><li>35: up to 90 L/min</li><li>70: up to 170 L/min</li></ul></li></ul><h4>Electrical</h4><ul><li>115 / 230 V</li><li>50–60 Hz</li><li>Power consumption: 200 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li><li>Humidity: 5–80%</li><li>Max altitude: 2000 m</li></ul><h4>Dimensions</h4><ul><li>92 × 26.5 × 75 cm</li></ul><h4>Weight</h4><ul><li>NITRO 35: 75 kg</li><li>NITRO 70: 90 kg</li></ul><h4>Communication</h4><ul><li>MODBUS (TCP), MQTT, HTTPS</li><li>Wi-Fi connectivity</li></ul><h4>Protection</h4><ul><li>IP20</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>100 L reservoir (air or nitrogen storage)</li><li>Installation kit for LC/MS (A200)</li><li>Dual Purity module (99.999% for LC-MS collision cell)</li></ul>

Organomation FLO Nitrogen Generator

The Organomation FLO provides adjustable nitrogen purity with integrated storage, real-time monitoring, and PSA technology for flexible lab applications.

The Organomation FLO (N2 FLO Series) is an advanced nitrogen generator based on PSA technology, designed for applications requiring flexible purity control and continuous operation.The system includes an oxygen analyzer and pressure regulator, enabling real-time nitrogen purity monitoring. Thanks to its integrated storage tank, no external buffer is required – one vessel serves both as buffer and supply reservoir.The generator automatically switches to energy-saving standby mode when production exceeds demand. An air quality analyzer (humidity and oil particles) ensures protection of the system and gas purity.The unit supports digital control and integration via MODBUS, MQTT, and HTTP protocols. An optional E941 food-grade configuration is available.<h4>Key Features</h4><ul><li>PSA technology (Claind Fast Purity)</li><li>Real-time nitrogen purity monitoring (O₂ analyzer)</li><li>Integrated storage tank (no buffer required)</li><li>Automatic standby mode for energy savings</li><li>Adjustable nitrogen purity</li><li>Digital control and communication (MODBUS, MQTT, HTTP)</li><li>Air quality protection (humidity, oil, particles)</li><li>Unattended continuous operation</li><li>Optional food-grade configuration (E941)</li></ul><h4>Available Models</h4><ul><li>N2 FLO 1</li><li>N2 FLO 2</li><li>N2 FLO 3</li><li>N2 FLO 4</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator</li><li>Oxygen analyzer</li><li>Pressure regulator</li><li>Digital control system</li><li>Integrated nitrogen tank</li><li>Air quality protection system</li><li>Communication interfaces (MODBUS, MQTT, HTTP)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: PSA (Fast Purity)</li><li>Dew point: -50 °C</li><li>Output pressure: 1.5 bar below inlet pressure</li><li>Noise: ≤ 60 dB</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115 / 230 V</li><li>50–60 Hz</li><li>Power consumption: 50 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li></ul><h4>Air Input Requirements</h4><ul><li>Pressure: 6.5–13 bar</li><li>Quality: ISO 8573-1 Class 1.4.1</li><li>Dry, clean, oil-free air</li></ul><h4>Dimensions</h4><ul><li>118 × 40 × 80 cm</li></ul><h4>Weight</h4><ul><li>FLO 1: 92 kg</li><li>FLO 2: 113 kg</li><li>FLO 3: 134 kg</li><li>FLO 4: 155 kg</li></ul><h4>Performance vs Purity (L/min at 8.5 bar, 20 °C)</h4><h5>N2 FLO 1</h5><ul><li>99.999%: 3 L/min</li><li>99.99%: 6 L/min</li><li>99.9%: 15 L/min</li><li>99.5%: 25 L/min</li><li>99%: 33 L/min</li><li>98%: 40 L/min</li><li>97%: 46 L/min</li></ul><h5>N2 FLO 2</h5><ul><li>99.999%: 8 L/min</li><li>99.99%: 13 L/min</li><li>99.9%: 30 L/min</li><li>99.5%: 48 L/min</li><li>99%: 60 L/min</li><li>98%: 76 L/min</li><li>97%: 88 L/min</li></ul><h5>N2 FLO 3</h5><ul><li>99.999%: 11 L/min</li><li>99.99%: 20 L/min</li><li>99.9%: 43 L/min</li><li>99.5%: 71 L/min</li><li>99%: 88 L/min</li><li>98%: 111 L/min</li><li>97%: 130 L/min</li></ul><h5>N2 FLO 4</h5><ul><li>99.999%: 16 L/min</li><li>99.99%: 28 L/min</li><li>99.9%: 61 L/min</li><li>99.5%: 96 L/min</li><li>99%: 120 L/min</li><li>98%: 151 L/min</li><li>97%: 176 L/min</li></ul>

Organomation MAXI Nitrogen Generator

The Organomation MAXI delivers high-capacity nitrogen generation with PSA technology, real-time monitoring, and scalable industrial performance.

The Organomation MAXI (N2 MAXI Series) is a high-capacity industrial nitrogen generator based on PSA Fast Purity technology, designed for applications requiring very high flow rates and stable nitrogen supply.The system includes an oxygen analyzer and pressure regulator, enabling real-time purity monitoring. Its integrated tank eliminates the need for a buffer vessel, combining storage and delivery in one system.The generator automatically switches to energy-saving standby mode when production exceeds consumption. An air quality monitoring system (humidity and oil) protects both performance and gas purity.Full IT integration is enabled via MODBUS, MQTT, and HTTP, with an optional E941 food-grade configuration.<h4>Key Features</h4><ul><li>PSA technology (Claind Fast Purity)</li><li>Very high flow rates (up to thousands L/min)</li><li>Real-time nitrogen purity monitoring</li><li>Integrated storage tank (no buffer required)</li><li>Automatic standby mode</li><li>Adjustable purity levels</li><li>Digital control with IT integration</li><li>Air quality protection system</li><li>Unattended continuous operation</li><li>Optional food-grade configuration (E941)</li></ul><h4>Available Models</h4><ul><li>N2 MAXI 1</li><li>N2 MAXI 2</li><li>N2 MAXI 3</li><li>N2 MAXI 4</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator</li><li>Oxygen analyzer</li><li>Pressure regulator</li><li>Digital control system</li><li>Integrated nitrogen tank</li><li>Air quality monitoring system</li><li>Communication interfaces (MODBUS, MQTT, HTTP)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: PSA (Fast Purity)</li><li>Dew point: -50 °C</li><li>Output pressure: 1.5 bar below inlet pressure</li><li>Noise: ≤ 60 dB</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115 / 230 V</li><li>50–60 Hz</li><li>Power consumption: 50 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li></ul><h4>Air Input Requirements</h4><ul><li>Pressure: 6.5–13 bar</li><li>Quality: ISO 8573-1 Class 1.4.1</li><li>Dry, clean, oil-free air</li></ul><h4>Dimensions</h4><ul><li>Height: 207.5 cm</li><li>Depth: 117 cm</li><li>Width:<ul><li>MAXI 1: 62 cm</li><li>MAXI 2: 103 cm</li><li>MAXI 3: 142 cm</li><li>MAXI 4: 182 cm</li></ul></li></ul><h4>Weight</h4><ul><li>MAXI 1: 730 kg</li><li>MAXI 2: 1400 kg</li><li>MAXI 3: 2050 kg</li><li>MAXI 4: 2700 kg</li></ul><h4>Performance vs Purity (L/min at 8.5 bar, 20 °C)</h4><h5>N2 MAXI 1</h5><ul><li>99.999%: 103 L/min</li><li>99.99%: 150 L/min</li><li>99.9%: 311 L/min</li><li>99.5%: 518 L/min</li><li>99%: 651 L/min</li><li>98%: 828 L/min</li><li>97%: 931 L/min</li></ul><h5>N2 MAXI 2</h5><ul><li>99.999%: 206 L/min</li><li>99.99%: 300 L/min</li><li>99.9%: 623 L/min</li><li>99.5%: 1,035 L/min</li><li>99%: 1,311 L/min</li><li>98%: 1,648 L/min</li><li>97%: 1,850 L/min</li></ul><h5>N2 MAXI 3</h5><ul><li>99.999%: 310 L/min</li><li>99.99%: 450 L/min</li><li>99.9%: 935 L/min</li><li>99.5%: 1,553 L/min</li><li>99%: 1,965 L/min</li><li>98%: 2,483 L/min</li><li>97%: 2,780 L/min</li></ul><h5>N2 MAXI 4</h5><ul><li>99.999%: 413 L/min</li><li>99.99%: 600 L/min</li><li>99.9%: 1,246 L/min</li><li>99.5%: 2,070 L/min</li></ul>

Organomation PICO Nitrogen Generator

The Organomation PICO delivers flexible nitrogen generation with adjustable purity, integrated storage, and real-time monitoring.

The Organomation PICO (N2 PICO Series) is a compact and high-performance nitrogen generator based on PSA Fast Purity technology, designed for applications requiring flexible purity control and stable nitrogen supply.The system includes an oxygen analyzer and pressure regulator, enabling real-time purity monitoring. Its integrated tank eliminates the need for a buffer vessel, combining storage and delivery in one unit.The generator automatically switches to energy-saving standby mode when production exceeds consumption. An air quality analyzer (humidity and oil particles) protects system performance and gas quality.The system supports digital control and integration via MODBUS, MQTT, and HTTP, with an optional E941 food-grade configuration.<h4>Key Features</h4><ul><li>PSA technology (Claind Fast Purity)</li><li>Real-time nitrogen purity monitoring</li><li>Integrated storage tank (no buffer required)</li><li>Automatic standby mode</li><li>Adjustable nitrogen purity</li><li>Digital control and communication (MODBUS, MQTT, HTTP)</li><li>Air quality protection system</li><li>Unattended continuous operation</li><li>Optional food-grade configuration (E941)</li></ul><h4>Available Models</h4><ul><li>N2 PICO 3</li><li>N2 PICO 4</li><li>N2 PICO 5</li><li>N2 PICO 6</li></ul><h4>Standard Features</h4><ul><li>PSA nitrogen generator</li><li>Oxygen analyzer</li><li>Pressure regulator</li><li>Digital control system</li><li>Integrated nitrogen tank</li><li>Air quality monitoring system</li><li>Communication interfaces (MODBUS, MQTT, HTTP)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: PSA (Fast Purity)</li><li>Dew point: -50 °C</li><li>Output pressure: 1.5 bar below inlet pressure</li><li>Noise: ≤ 60 dB</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115 / 230 V</li><li>50–60 Hz</li><li>Power consumption: 50 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li></ul><h4>Air Input Requirements</h4><ul><li>Pressure: 6.5–13 bar</li><li>Quality: ISO 8573-1 Class 1.4.1</li><li>Dry, clean, oil-free air</li></ul><h4>Dimensions</h4><ul><li>138 × 40 × 130 cm</li></ul><h4>Weight</h4><ul><li>PICO 3: 230 kg</li><li>PICO 4: 270 kg</li><li>PICO 5: 310 kg</li><li>PICO 6: 350 kg</li></ul><h4>Performance vs Purity (L/min at 8.5 bar, 20 °C)</h4><h5>N2 PICO 3</h5><ul><li>99.999%: 25 L/min</li><li>99.99%: 41 L/min</li><li>99.9%: 90 L/min</li><li>99.5%: 143 L/min</li><li>99%: 173 L/min</li><li>98%: 230 L/min</li><li>97%: 268 L/min</li></ul><h5>N2 PICO 4</h5><ul><li>99.999%: 33 L/min</li><li>99.99%: 55 L/min</li><li>99.9%: 115 L/min</li><li>99.5%: 191 L/min</li><li>99%: 250 L/min</li><li>98%: 306 L/min</li><li>97%: 345 L/min</li></ul><h5>N2 PICO 5</h5><ul><li>99.999%: 38 L/min</li><li>99.99%: 66 L/min</li><li>99.9%: 153 L/min</li><li>99.5%: 240 L/min</li><li>99%: 306 L/min</li><li>98%: 383 L/min</li><li>97%: 441 L/min</li></ul><h5>N2 PICO 6</h5><ul><li>99.999%: 58 L/min</li><li>99.99%: 83 L/min</li><li>99.9%: 173 L/min</li><li>99.5%: 288 L/min</li><li>99%: 365 L/min</li><li>98%: 460 L/min</li><li>97%: 518 L/min</li></ul>

Products from category Laboratory gases and gas generators - page 1
