DataApex Clarity Offline Chromatography Software

Clarity Offline allows users to import previously acquired data and to evaluate and prepare methods in regulated environment.

Clarity Offline allows users to import previously acquired data and to evaluate and prepare methods. This version cannot acquire data, but it can share data or even directly access (through LAN) projects of the <a href="https://lcms.labrulez.com/products/999">Clarity</a> and Clarity Lite software. With Clarity Offline users are able to work with acquired data on additional computers in the lab or at home. The software works with the same files and provides the same outputs (printing and exporting) as Clarity and Clarity Lite.
Clarity Offline is intended for use as additional software that supplements Clarity and Clarity Lite. It can also be used to evaluate data from other manufacturers&#39; CDS.
<blockquote>
Ask for <a href="https://www.dataapex.com/product/clarity-demo">Clarity Demo version</a> which allows you to get your hands on software before purchase
</blockquote>
<h3>Main features</h3>
<ul>
<li>21 CFR Part 11 compliance: Clarity Offline contains all functions (Electronic Signatures, User Accounts, Audit Trail, etc.) for compliance with the 21 CFR Part 11 directive of the FDA. Clarity Offline can be used for evaluation in regulated environments.
</li>
<li>Networked Solution: Clarity Offline can access files of Clarity and Clarity Lite installed on networked computers. This enables evaluation of chromatograms, development of new methods, and printing reports on additional computers in the laboratory.
</li>
<li>Education: An additional field of use is in education. Students can process chromatograms that have been acquired from Clarity connected to a chromatograph using their Clarity Offline license. Thus they do not need a Clarity full license just for data evaluation.
</li>
<li>Data processing and evaluation from other chromatography software: Clarity Offline allows the import of data from other chromatography software using text or AIA import function. This allows the user to process and evaluate chromatograms acquired by other chromatography software.
</li>
<li>Offsite computer: Clarity Offline can be installed on any Windows computer, giving you anytime access to your chromatographic data (USB hardware key is required).
</li>
<li>Language Localizations available: Useful for non-English speakers. At the moment, there are French, German, Russian, Spanish, and Chinese localizations available in a single installation package. Simply switch to your preferred language anytime.
</li>
</ul>
<a href="https://www.dataapex.com/controls">List of supported instruments</a>
<a href="https://www.dataapex.com/product/clarity-std-compatibility">Compatible Windows OS and Hardware</a>
<a href="https://www.dataapex.com/product/clarity-21cfr-compliance">Clarity 21 CFR Part 11 compliance</a>

DataApex SST - System Suitability Test Extension for Clarity

The SST extension serves to monitor the correct function of the chromatography system. The program compares up to 12 selected parameters (e.g., retention time, efficiency, asymmetry of peaks) calculated according to one of three pre-selected methods (USP, EP, JP).

<h3>The SST extension serves to monitor the correct function of the chromatography system.</h3>
The program compares up to 12 selected parameters (e.g., retention time, efficiency, asymmetry of peaks) calculated according to one of three pre-selected methods (USP, EP, JP). These calculated values are either compared to the user&#39;s set limit values for each chromatogram separately or together for the selected series. Deviation of any parameter from the permissible limits is immediately reported and may lead to the termination of the sequence in progress. The SST Extension allows the user to monitor the parameters of individual substances and thus evaluate the reproducibility of the results of the entire chromatography system.
The SST extension is required when using the <a href="https://www.dataapex.com/product/validation-kit">Validation Kit</a>.
<h3>Main features</h3>
<ul>
<li>Measuring: Simultaneous data acquisition from up to four signals (detectors) attached to one chromatograph.
</li>
<li>Parameters: The program compares up to 12 selected parameters (e.g., retention time, efficiency, asymmetry of peaks) calculated according to one of three pre-selected methods (USP, EP, JP).
</li>
<li>Limit values: These calculated values are compared to user set limit values, either for each chromatogram separately or together for the selected series. Deviation of a certain parameter from the permissible limits is immediately reported and may lead to the termination of the sequence in progress.
</li>
<li>Versatility: Even though validation primarily focuses on testing system reliability, it can also be used in many other ways. Validation can be run during measurements, or additionally, using batch processing. Validated data can be automatically saved to a database file for further processing.
</li>
<li>Enhanced sequencing: In connection with a sequence, the SST module can even pause a sequence when a specified value has been exceeded or to perform predefined functions.
</li>
</ul>
<a href="https://gcms.labrulez.com/products/999">Clarity</a> Chromatography Software required

DataApex MS - Mass Spectrometry Extension for Clarity

The Clarity MS Extension is a tool that is used for processing data that has been acquired from selected Mass Spectrometry detectors. Spectral data, together with chromatograms, add a third dimension to analytical data analysis.

<h3>Clarity Extension for processing data that has been acquired from selected Mass Spectrometry detectors</h3>
The Clarity MS Extension is a tool that is used for processing data that has been acquired from selected Mass Spectrometry detectors. Spectral data, together with chromatograms, add a third dimension to analytical data analysis.
The MS Extension expands the capability of <a href="https://lcms.labrulez.com/products/999">Clarity</a> and <a href="https://lcms.labrulez.com/products/1000">Clarity Offline</a> Chromatography software by providing interactive spectral analysis, peak purity analysis, and compound identification that is based on a spectral <a href="https://gcms.labrulez.com/products?category=249">library</a> search. The extension is prepared to function with single quadrupole MS detectors and TOF MS detectors.
All data is saved in a single file; a chromatogram at any m/z value or even only a spectrum can simply be recalled for review after an analysis. MS spectra, acquired using an MS detector, may be interactively selected from a chromatogram signal for visual inspection and comparison. The spectra may also be used for peak purity determinations and component identification through spectral <a href="https://lcms.labrulez.com/products?category=285">libraries</a>.
It is possible to import MS data in AIA (cdf), mzXML, MzML, and mzData formats.
Control modules for selected detectors (see <a href="https://www.dataapex.com/controls">list of control modules</a>) are available in Clarity. Additional control modules for MS detectors can be developed upon request.

Watrex LSS-205 Liquid Sensing System

Liquid Sensing System LSS-205 is a universal sensing system for monitoring the level of your chromatographic system liquids.

Universal sensing system for monitoring the level of your chromatographic system liquids. The daily task in the chromatographic laboratory is the manipulation of mobil phases. The operator must check the supply of solvents at the inlet of the device and regular monitor the condition of the waste solvent container. The LSS-205 greatly simplifies these tasks.<blockquote>Price: 578<bdi>&nbsp;€ ex VAT</bdi></blockquote>LSS-205 is a universal accessory for any (chromatographic) system. The level sensors used in the LSS-205 system are contactless, do not require immersion in liquid, and are installed on the outer shell of a non-metallic solvent container. The method of mounting the sensor allows placement on a container of virtually any shape and size.The LSS-205 central unit is ready to process the signal from up to five liquid sensors, which can be individually set to trigger an alarm in the event of a missing or present liquid. The error status of the individual sensors is indicated optically directly on the central unit and the alarm can be accompanied by an acoustic signal. An external loud siren suitable for a noisy environment is available as an option to the central unit.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Watrex_LSS_205_Liquid_Sensing_System_33_0fd5d29a02/Watrex-LSS-205-Liquid-Sensing-System-33.jpg" alt="Watrex LSS-205 Liquid Sensing System"><h3>FEATURES</h3><ul><li>Simple operation</li><li>Flexible in application</li><li>Multiple connection option</li><li>Starter kit contents: central unit, one sensor, light bar, power supply</li><li>Color touch panel control</li></ul><h3>TECHNICAL SPECIFICATION</h3><ul><li>Power supply: 5V DC (wall mount power supply or USB port of PC)</li><li>Number of liquid sensors: 1 – 5</li><li>Alarm condition: individually adjustable for each sensor (off, missing liquid, liquid present)</li><li>Internal alarm indication: high intensity LED for each sensor</li><li>Internal acoustic alarm: 80dB, common for all sensors</li><li>External optical signaling: connector on the central unit</li><li>External acoustic alarm: optional 105 dB external horn</li><li>Alarm signal for external devices: logic (open collector), relay switching contact</li><li>Computer connection: micro USB connector, simple text communication protocol</li><li>Firmware update: possible in field</li><li>Dimension: 130x80x30 mm</li><li>Weight: 250 g</li><li>Sensor dimensions: 50x30x15 mm</li><li>Sensor connection cable: 2 m length</li><li>Sensor mounting: plastic holder with flexible silicon tube (length 700 mm, other lengths on request)</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Watrex_LSS_205_Liquid_Sensing_System_6_7b35aadbb7/Watrex-LSS-205-Liquid-Sensing-System-6.jpg" alt="Watrex LSS-205 Liquid Sensing System - level sensor"><h3>Ordering information:</h3><h5>PN/Component:</h5><ul><li>40-0728 Starter Kit (incl. 1 sensor + light)</li><li>40-0738 LSS-205 Additional Sensor</li><li>40-0841 LSS-205 Additional 2 Sensors</li><li>40-0842 LSS-205 Additional 3 Sensors</li><li>40-0843 LSS-205 Additional 4 Sensors</li><li>40-0838 LSS-205 External Alarm Horn</li></ul>

ARC Polyarc System

A Breakthrough Innovation Revolutionizing GC/FID Technology. The Polyarc System is transforming the way scientists use gas chromatographs with Flame Ionization Detectors.

The Polyarc system has a catalytic microreactor that enhances new and existing gas chromatographs (GCs) with flame ionization detectors (FIDs) by converting all organic compounds to methane molecules prior to their detection by the FID. In doing so, the Polyarc system reduces the need to perform time-consuming calibrations by creating a uniform detector response for truly universal carbon detection.
The Polyarc system gives scientists the capability to determine purity, quantify unknowns, qualify products, investigate, improve development and more in a simple, fast and more economical way that is transforming the industry.
<blockquote>
Available for gas chromatographs (GC) <a href="https://gcms.labrulez.com/products?category=1&amp;manufacturerItems=10">Agilent</a> 5890, 6890, 7820, 7890, 8890, <a href="https://gcms.labrulez.com/products?category=1&amp;manufacturerItems=1">Shimadzu</a> 2030, <a href="https://gcms.labrulez.com/products?category=1&amp;manufacturerItems=3">Thermo Fisher</a>, Varian, Bruker a Scion GC.
</blockquote>
<h3>What is Polyarc?</h3>
The Polyarc is the next evolution of flame ionization detection (FID). The Polyarc converts the FID into a truly universal carbon detector using proprietary catalytic reactions that convert organic molecules to methane immediately prior to detection.
<h3>Why is it important?</h3>
The FID has two main challenges: lack of uniform response and low response to certain compounds. The Polyarc enhances your FID to solve these challenges by giving your FID a uniform response to nearly all organic molecules. The result is more accurate data, improved productivity, lab efficiencies, and the ability to detect more compounds.
<h3>How Does the Polyarc® System Work to Simplify and Improve GC/FID Quantification?</h3>
The Polyarc system has a catalytic microreactor that enhances GC/FIDs by converting all organic compounds to methane molecules prior to detection by the FID. The result?
A universal response for ALL organic molecules.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Polyarc_FID_vs_FID_Response_Factors_0f9c958558/ARC-PolyarcFID-vs-FID-Response-Factors.jpg" alt="ARC: Comaprison of Polyarc/FID vs FID Response Factors.jpg"/>
<h3>The Polyarc System Features an Optimized Design and Seamless Integration</h3>
The Polyarc system is the first commercial technology of its kind. The device uses proprietary technologies including novel catalysts, a specially designed 3D-printed micro reactor, and fast seamless integration into existing equipment.
The optimized internal design and catalyst microstructure maintains separation performance and peak shape while increasing sensitivity and enabling accurate quantification without calibration standards.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Optimalizovany_design_a_specialne_navrzeny_3_D_tisteny_mikroreaktor_Polyarc_70ccedc41e/ARC-Optimalizovany-design-a-specialne-navrzeny-3D-tisteny-mikroreaktor-Polyarc.jpg" alt="ARC: Specially designed 3D-printed micro reactor Polyarc"/>
<h3>Perform Cutting-Edge Chromatography on Any Organic Compound with a Polyarc® System</h3>
Realize a greater breadth of analysis with improved detection of compounds previously invisible or with an extremely low sensitivity by gas chromatography using FID only — while reducing the need for time intensive calibration.
The careful selection and robust catalyst design enables the analysis of a wide variety of compounds including a range of heteroatoms, compounds of various sizes, and samples containing common catalytic poisons (e.g., S).
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Analyza_siroke_skaly_sloucenin_pomoci_Polyarc_systemu_3e18241358/ARC-Analyza-siroke-skaly-sloucenin-pomoci-Polyarc-systemu.png" alt="ARC: Polyarc system enables the analysis of a wide variety of compounds"/>
<h3>How Does the Polyarc System Compare to a Methanizer?</h3>
A conventional methanizer converts CO and CO₂ to methane, allowing low level FID detection of CO and CO₂. The significant advantage of the Polyarc system is that it converts all compounds to methane, allowing not only for the detection of CO and CO₂ , but also millions of other organic compounds.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Srovnani_systemu_Polyarc_s_metanizerem_7df16e09c7/ARC-Srovnani-systemu-Polyarc-s-metanizerem.jpg" alt="ARC: Comparison of the Polyarc System with a metanizer"/>

ARC Jetanizer (Methanizer)

The Jetanizer is the easiest and most robust methanizer.

<h3>What is Jetanizer™?</h3>
The Jetanizer is the easiest and most robust methanizer. A methanizer is a chemical reactor that converts carbon dioxide and carbon monoxide to methane to enable sensitive detection by a flame ionization detector (FID) from &lt;20 ppb to 100%!
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Analyza_CO_2_od_1ppm_do_100_s_pouzitim_GC_jetanizeru_FID_9c922be2e9/ARC-Analyza-CO2-od-1ppm-do-100percent-s-pouzitim-GC-jetanizeru-FID.jpg" alt="ARC: CO₂ analysis from 1ppm to 100% with GC/Jetanizer/FID"/>
<h3>Why is it important?</h3>
<h4>Low-level detection of CO and CO₂ is important in:</h4>
<ul>
<li>catalysis </li>
<li>hydrogen (H₂) purity analysis </li>
<li>dissolved gas analysis (DGA)</li>
<li>greenhouse gas (GHG) analysis, </li>
<li>transformer oil gas analysis (TOGA)</li>
<li>ethylene/propylene monomers analysis </li>
<li>safe entry analysis, and more</li>
</ul>
Traditionally, large nickel-catalyst-filled tube methanizers are used, however, they are prone to frequent failures, and they are difficult and time consuming to operate and maintain.
<blockquote>
Legacy nickel catalyst methanizers take 2-6 hours to install and replace. Jetanizers take &lt;5 minutes.
</blockquote>
ARC’s Jetanizer solves these challenges by improving response, robustness and ease of installation, by incorporating state-of-the-art catalysts into an FID jet. Moreover, the Jetanizer enables low level &lt;1 ppm formaldehyde analysis by GC avoiding the pitfalls of HPLC analysis of formaldehyde.
<blockquote>
For use with these GC models: <a href="https://gcms.labrulez.com/products?category=1&amp;manufacturerItems=10">Agilent 5890, 6890, 7890, 8890, Intuvo</a>, <a href="https://gcms.labrulez.com/products?category=1&amp;manufacturerItems=1">Shimadzu 2010, 2030 GC</a>.
</blockquote>
<h3>Benefits over Traditional Methanizers</h3>
<ul>
<li>Lower up-front cost</li>
<li>No extra plumbing: minimize fittings and leaks</li>
<li>No extra heater or controller: utilizes heat from FID</li>
<li>FAST installation: Less than 5 minutes</li>
<li>Ability to be used with formaldehyde</li>
<li>Higher sulfur tolerance</li>
<li>Higher catalytic activity = larger linear dynamic range</li>
<li>Free up space on the GC</li>
<li>No toxic metals: The Jetanizer™ does not contain nickel catalysts</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Kalibrace_analyzy_CO_2_s_pouzitim_GC_jetanizeru_FID_2f0b6171fc/ARC-Kalibrace-analyzy-CO2-s-pouzitim-GC-jetanizeru-FID.jpg" alt="ARC: CO₂ analysis calibration with GC/Jetanizer/FID"/>

ARC GCxGC Xpansion

ARC’s simple stop-flow modulator can be installed in minutes and turn any GC into a powerful multi-dimensional separation machine. ARC’s modulator emphasizes robustness, simplicity, and ease of use to allow anyone from a novice GC user to a veteran expert to generate valuable chemical data on the most complex samples.

<h3>No-fuss GCxGC solution</h3>
This affordable package includes free, open-source software (visualization only), and ARC’s lifetime support. For power users we offer GC Image software.
<h3>Why choose us?</h3>
<ul>
<li>Affordable</li>
<li>Robust design</li>
<li>Simple and easy self-installation or professional installation</li>
<li>Dramatically increased peak capacity</li>
<li>Easily switch between 1D and 2D GC</li>
<li><a href="https://www.activatedresearch.com/gcxgc_vis/">Free visualization software</a></li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_ARC_G_Cx_GC_Xpansion_9536cf0985/ARC-ARC-GCxGC-Xpansion.jpg" alt="ARC: ARC GCxGC Xpansion solution"/>
<h3>Why should I use GCxGC?</h3>
The separation of compounds by gas chromatography is typically performed using a single analytical column. As samples become more complex, it can become difficult to separate all the compounds from each other and they can start to overlap, or co-elute. Longer or narrower columns can be used to increase resolving power, but with diminishing returns.
Comprehensive two-dimensional GC, or GCxGC, drastically increases separation power by adding a second analytical column after the first column. A modulator placed between the two columns pulses the analytes from the first column onto the second column. When the columns are orthogonal in separation power, this technique can result in an order of magnitude increase in the number of analytes that can be detected.
ARC’s solution takes advantage of stop-flow modulation to make GCxGC an attainable configuration for any analytical laboratory. It involves continually sampling the effluent from the first column into an accumulator tube and re-injecting it onto a second, smaller column with orthogonal separation. This second separation happens in the time it takes to accumulate the next sample. The pulse time is known as the modulation time.

ARC Precision Split

ARC’s PrecisionSplit device allows scientists and chromatographers to take advantage of the quantitative power of the Polyarc/FID in combination with the mass identification power of the mass spectrometer, all in the same injection in real time.

<h3>Why does my MS need an FID?</h3>
A mass spectrometer (MS) provides valuable qualitative data, but poses several challenges to accurate quantification. Adding a flame ionization detector (FID) in parallel with the MS gives complementary quantitative carbon concentrations with minimal extra effort or equipment. We believe every MS needs an FID companion for quantitative analysis, especially for non-targeted analysis or tentatively identified compounds where quantification is desired.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Precision_Split_6271ed1240/ARC-Precision-Split.jpg" alt="ARC: Precision Split"/>
<h3>The benefits of a MS/FID split:</h3>
<ul>
<li>Virtually eliminate response factor variability</li>
<li>Quantify accurately (better linearity, more consistent response, fewer calibration errors)</li>
<li>Improve sensitivity for poor ionizers with the FID</li>
<li>Save your source!</li>
</ul>
<h3>The Data</h3>
Response factor (RF) variation in the mass spectrometer (i.e., the relative response of the MS to different chemicals) can lead to significant errors in quantification. Two compounds that have the same response/area in the MS can have concentrations that differ more than 100-fold (see <a href="https://www.sciencedirect.com/science/article/pii/S0731708520304283">Jordi et al.</a>).
As you can see below, the Polyarc/FID split can reduce this response factor variation so that accurate quantification of tentatively identified compounds is possible.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Variance_RF_u_MS_detektoru_8e02773edc/ARC-Variance-RF-u-MS-detektoru.jpg" alt="ARC: RF variation with MS"/>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_Variance_RF_s_Polyarc_FID_splittrem_ca7def3cb3/ARC-Variance-RF-s-Polyarc-FID-splittrem.jpg" alt="ARC: RF variation with Polyarc/FID split"/>

ARC ISOTOPE (COMBUSTION REACTOR FOR IRMS)

The World’s First Low Temperature Combustion Reactor for GCC-IRMS

Winner of <a href="https://theanalyticalscientist.com/techniques-tools/tasias-2018-strokes-of-genius">The Analytical Scientist Innovation Awards in 2018</a>, the ARC Isotope was developed for low-temperature combustion of steroids and hydrocarbons for carbon isotope measurements.
The system easily integrates into existing instrumentation and outperforms conventional combustion reactors.
<h3>GCC-IRMS Chromatograms of steroids and alkanes using the ARC Isotope reactor show excellent performance and operability compared with legacy reactors.</h3>
<h4>Advantages Include:</h4>
<ul>
<li>Excellent Performance</li>
<li>Lower Operating Temperature</li>
<li>Reduced Complexity</li>
<li>Improved Robustness</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/ARC_GCC_IRMS_chromatogramy_steroidu_a_alkanu_s_pouzitim_reaktoru_ARC_ISOTOPE_d6299edd7a/ARC-GCC-IRMS-chromatogramy-steroidu-a-alkanu-s-pouzitim-reaktoru-ARC-ISOTOPE.jpg" alt="ARC: GCC-IRMS chromatograms of steroids and alkanes using ARC ISOTOPE reactor"/>
Data provided by Tobias, H.J., et al., Analytical Chemistry, <a href="https://pubs.acs.org/doi/10.1021/acs.analchem.8b05043">Read More</a>

DataApex Clarity Chromatography Software

Clarity is a chromatography data software for data acquisition, processing, and instrument control in regulated environment. Clarity is a flexible solution for devices from different vendors, supporting different applications.

Optional control modules provide integrated control of selected instruments such as GCs, LCs, pumps, detectors, autosamplers, etc. Extensions provide functions for specific separation techniques or calculations such as PDA, GPC analysis, Mass spectrometry, or SST. Clarity can run in English, French, German, Russian, Spanish, and Chinese language. Support technicians and developers are close to their users and ready to provide extensive Support from DataApex.
<blockquote>
Ask for <a href="https://www.dataapex.com/product/clarity-demo">Clarity Demo version</a> which allows you to get your hands on software before purchase
</blockquote>
<h3>Main features</h3>
<ul>
<li>Measuring: Simultaneous data acquisition from up to four independent chromatographs, each chromatograph can acquire data from up to 32 detectors.
</li>
<li>Integration: There is an extensive possibility to modify chromatograms. The chromatogram can be changed by entering global parameters or interactively through direct graphic modification of the baseline.
</li>
<li>Overlay: Simultaneously displays a virtually unlimited number of chromatograms and their mathematical modification; for example, mutual deductions or derivations of any order.
</li>
<li>Calibration: Internal and external standard calculation methods, calibration of groups of peaks, and reference peaks method for better identification.
</li>
<li>Wide range of supported instruments: Control modules in Clarity allow users to control various instruments in their lab. See our growing <a href="https://www.dataapex.com/controls">List of supported instruments</a>.
</li>
<li>Extensions completing your workflow: Clarity Extensions integrates your workflow into one application. GPC calculations, PDA data processing, gas or detailed hydrocarbon analyses according to selected norms, and much more.
</li>
<li>Automated measuring support: Sequence tables for any set of samples with or without an autosampler.
</li>
<li>Postrun: Automatically displays, prints, exports, and starts other programs after the completion of a measurement.
</li>
<li>Summary result tables: Displays and prints selected results from all simultaneously displayed chromatograms.
</li>
<li>User settings: User selects parameters for peak display and the specification for axes, including color from an extensive array of color settings. Text labels and lines, either as part of the area or anchored to a chromatogram, may also be inserted.
</li>
<li>Export: Optional exportation of all results, with or without the chromatogram, in various formats, into a file or clipboard.
</li>
<li>Import: Imports chromatograms or mathematical curves, which have been saved in text or AIA formats, from other programs.
</li>
<li>LIMS: Clarity offers connectivity with LIMS, both for sample submission and result output. This can be done via convenient ASCII transfers.
</li>
<li>Method and calibration history: Each chromatogram can easily be displayed under the same conditions as when it was printed, exported, or saved.
</li>
<li>Column performance: Calculations of peaks in terms of symmetry, efficiency, resolution; all by several methods (tangent, moments, etc.).
</li>
<li>Batch: Automatically batch processes, displays, exports, or prints any number of chromatograms.
</li>
<li>User calculations: Users can define custom calculations in the Result and Summary tables. Using the integrated editor, you can create your own columns from original columns and individual mathematical functions.
</li>
<li>User accounts: Sets up access rights and passwords (including their parameters, e.g., minimum length, validity, etc.). Each user can define his or her own appearance of the software.
</li>
<li>Audit trail: Records selected events and operations into a special file. Records selected operations directly into a chromatogram.
</li>
<li>Electronic signature: Each chromatogram can be signed electronically. Signature selection is based on the username or the signature certificate.
</li>
<li>Networked Solution: Clarity chromatography software files can be accessed from networked computers using Clarity Offline software. This enables the offline evaluation of chromatograms, development of new methods, and printing reports. See the <a href="https://gcms.labrulez.com/products/1000">Clarity Offline</a> for more details.
</li>
<li>Language Localizations available: Useful for non-English speakers. At the moment, there are French, German, Russian, Spanish, and Chinese localizations available in a single installation package. Simply switch to your preferred language anytime.
</li>
<li>Competitive approach: The chromatography market offers many specialized HPLC data systems or GC data systems; these are often provided with the purchased instrument. It is usually complicated to integrate such software into the workflow of the laboratory since they do not enable direct control of additional instruments. Compared to other small-scale solutions, Clarity offers a wide range of directly controlled instruments as well as optional Extensions for specific separation techniques. On the other hand, complex solutions with a wide scope of features and scalable design are quite expensive, which is a limiting factor for many customers. Another drawback of the large solutions is their complexity which imposes high demands on users. Compared to this, Clarity represents a scalable medium-ranged solution with a steep learning curve and competitive prices.
</li>
</ul>
<h3>Clarity configurations examples</h3>
<h4>One chromatograph with two detectors</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_One_chromatograph_with_two_detectors_ae482b83b8/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-One-chromatograph-with-two-detectors.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - One chromatograph with two detectors.jpg"/>
<ul>
<li>The HPLC measures on two detectors. Clarity will acquire two separate signals sharing a common timebase (synchronized START/STOP). A resulting chromatogram will contain two signals.</li>
</ul>
<h4>Two chromatographs, one with multiple detectors</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Two_chromatographs_one_with_multiple_detectors_b21dc07faf/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Two-chromatographs-one-with-multiple-detectors.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Two chromatographs, one with multiple detectors.jpg"/>
<ul>
<li>This example displays a configuration with two chromatography systems (GC + HPLC) where the HPLC system uses multiple detectors. All the detectors attached to the HPLC Instrument will share common timebase (synchronized START/STOP). The GC detector will be independent.</li>
</ul>
<h4>Two chromatographs, one digital control</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Two_chromatographs_one_digital_control_1bf9cec334/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Two-chromatographs-one-digital-control.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Two chromatographs, one digital control.jpg"/> This example displays a configuration with two chromatography systems (GC + LC). The GC is connected and controlled via digital interface *, using a GC Control appropriate module.
<h4>Four chromatographs with autosampler each</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Four_chromatographs_with_autosampler_each_945873d808/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Four-chromatographs-with-autosampler-each.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Four chromatographs with autosampler each.jpg"/>
<ul>
<li>This example displays a configuration with two chromatography systems (GC + LC). The GC is connected and controlled via digital interface *, using a GC Control appropriate module.</li>
</ul>
<a href="https://www.dataapex.com/controls">List of supported instruments</a>
<a href="https://www.dataapex.com/product/clarity-std-compatibility">Compatible Windows OS and Hardware</a>
<a href="https://www.dataapex.com/product/clarity-21cfr-compliance">Clarity 21 CFR Part 11 compliance</a>

Related content

Effective Use of EI Mass Spectral Databases in Unknown Identifications - Part V: Creating and Sharing User EI and MS/MS Libraries

News from LabRulezGCMS Library - Week 40, 2024

Broadband Laser-Based Infrared Detector for Gas Chromatography
