Eaton HotSwap MBP 6000i G2 maintenance bypass

The Eaton HotSwap MBP 6000i G2 is a maintenance bypass designed to ensure power continuity during UPS servicing or replacement.

The unit allows the UPS to be disconnected without interrupting power to connected equipment. With a 3U form factor, it is suitable for standard 19" rack installations.

The HotSwap MBP provides IEC outlets (C13 and C39) and a hardwired output connection. It does not include outlet control or communication interfaces.

Key Features

• Maintenance bypass for UPS
• Ensures power continuity during UPS servicing
• 2× IEC C13 + 3× IEC C39
• 1× hardwired output
• 3U form factor for 19" rack
• Rack mounting kit included
• No outlet control
• No communication interfaces

Technical Specifications

General

• Product name: Eaton HotSwap MBP maintenance bypass
• Catalog number: MBP6KIG2
• Model code: Eaton HotSwap MBP 6000i G2
• EAN: 3553340684746
• Rack size: 3U
• Construction type: 482.6 mm (19 inch) device
• Dimensions (D × H × W): 125 × 130 × 177 mm
• Weight: 2 kg
• Compliances:
  • LVD Directive (CB)
  • EMC Directive
  • RoHS Directive
  • REACH
  • WEEE Directive
  • Packaging Directive
• Certifications:
  • IEC/EN 62040-1
  • IEC/EN 62040-2
  • IEC/EN 62040-3
  • CE
  • UKCA
  • Cm
  • Ukr
  • RCM

Application & accessory

• Type of accessory: bypass
• Used with: 9PX Gen2 (5/6 kVA) / 9SX Gen2 (5/6 kVA)

Output

• Receptacle: (2) C13, (3) C39
• Number of outputs hardwired: 1

Mounting

• Rack mounting kit: yes
• Mounting dimension (standardized): 482.6 mm (19 inch)

Operating conditions

• Temperature range: 0° to 40°C (32° to 104°F)

Package contents

• Maintenance bypass
• Connection cable to the UPS
• Rack mounting kit
• Quick start guide
