Organomation FLO Nitrogen Generator

The Organomation FLO (N2 FLO Series) is an advanced nitrogen generator based on PSA technology, designed for applications requiring flexible purity control and continuous operation.

The system includes an oxygen analyzer and pressure regulator, enabling real-time nitrogen purity monitoring. Thanks to its integrated storage tank, no external buffer is required – one vessel serves both as buffer and supply reservoir.

The generator automatically switches to energy-saving standby mode when production exceeds demand. An air quality analyzer (humidity and oil particles) ensures protection of the system and gas purity.

The unit supports digital control and integration via MODBUS, MQTT, and HTTP protocols. An optional E941 food-grade configuration is available.

Key Features

• PSA technology (Claind Fast Purity)
• Real-time nitrogen purity monitoring (O₂ analyzer)
• Integrated storage tank (no buffer required)
• Automatic standby mode for energy savings
• Adjustable nitrogen purity
• Digital control and communication (MODBUS, MQTT, HTTP)
• Air quality protection (humidity, oil, particles)
• Unattended continuous operation
• Optional food-grade configuration (E941)

Available Models

• N2 FLO 1
• N2 FLO 2
• N2 FLO 3
• N2 FLO 4

Standard Features

• PSA nitrogen generator
• Oxygen analyzer
• Pressure regulator
• Digital control system
• Integrated nitrogen tank
• Air quality protection system
• Communication interfaces (MODBUS, MQTT, HTTP)

Technical Specifications

General

• Technology: PSA (Fast Purity)
• Dew point: -50 °C
• Output pressure: 1.5 bar below inlet pressure
• Noise: ≤ 60 dB
• Protection class: IP20

Electrical

• 115 / 230 V
• 50–60 Hz
• Power consumption: 50 W

Operating Conditions

• Temperature: 5–40 °C

Air Input Requirements

• Pressure: 6.5–13 bar
• Quality: ISO 8573-1 Class 1.4.1
• Dry, clean, oil-free air

Dimensions

• 118 × 40 × 80 cm

Weight

• FLO 1: 92 kg
• FLO 2: 113 kg
• FLO 3: 134 kg
• FLO 4: 155 kg

Performance vs Purity (L/min at 8.5 bar, 20 °C)

N2 FLO 1

• 99.999%: 3 L/min
• 99.99%: 6 L/min
• 99.9%: 15 L/min
• 99.5%: 25 L/min
• 99%: 33 L/min
• 98%: 40 L/min
• 97%: 46 L/min

N2 FLO 2

• 99.999%: 8 L/min
• 99.99%: 13 L/min
• 99.9%: 30 L/min
• 99.5%: 48 L/min
• 99%: 60 L/min
• 98%: 76 L/min
• 97%: 88 L/min

N2 FLO 3

• 99.999%: 11 L/min
• 99.99%: 20 L/min
• 99.9%: 43 L/min
• 99.5%: 71 L/min
• 99%: 88 L/min
• 98%: 111 L/min
• 97%: 130 L/min

N2 FLO 4

• 99.999%: 16 L/min
• 99.99%: 28 L/min
• 99.9%: 61 L/min
• 99.5%: 96 L/min
• 99%: 120 L/min
• 98%: 151 L/min
• 97%: 176 L/min
