Organomation PICO Nitrogen Generator

The Organomation PICO (N2 PICO Series) is a compact and high-performance nitrogen generator based on PSA Fast Purity technology, designed for applications requiring flexible purity control and stable nitrogen supply.

The system includes an oxygen analyzer and pressure regulator, enabling real-time purity monitoring. Its integrated tank eliminates the need for a buffer vessel, combining storage and delivery in one unit.

The generator automatically switches to energy-saving standby mode when production exceeds consumption. An air quality analyzer (humidity and oil particles) protects system performance and gas quality.

The system supports digital control and integration via MODBUS, MQTT, and HTTP, with an optional E941 food-grade configuration.

Key Features

• PSA technology (Claind Fast Purity)
• Real-time nitrogen purity monitoring
• Integrated storage tank (no buffer required)
• Automatic standby mode
• Adjustable nitrogen purity
• Digital control and communication (MODBUS, MQTT, HTTP)
• Air quality protection system
• Unattended continuous operation
• Optional food-grade configuration (E941)

Available Models

• N2 PICO 3
• N2 PICO 4
• N2 PICO 5
• N2 PICO 6

Standard Features

• PSA nitrogen generator
• Oxygen analyzer
• Pressure regulator
• Digital control system
• Integrated nitrogen tank
• Air quality monitoring system
• Communication interfaces (MODBUS, MQTT, HTTP)

Technical Specifications

General

• Technology: PSA (Fast Purity)
• Dew point: -50 °C
• Output pressure: 1.5 bar below inlet pressure
• Noise: ≤ 60 dB
• Protection class: IP20

Electrical

• 115 / 230 V
• 50–60 Hz
• Power consumption: 50 W

Operating Conditions

• Temperature: 5–40 °C

Air Input Requirements

• Pressure: 6.5–13 bar
• Quality: ISO 8573-1 Class 1.4.1
• Dry, clean, oil-free air

Dimensions

• 138 × 40 × 130 cm

Weight

• PICO 3: 230 kg
• PICO 4: 270 kg
• PICO 5: 310 kg
• PICO 6: 350 kg

Performance vs Purity (L/min at 8.5 bar, 20 °C)

N2 PICO 3

• 99.999%: 25 L/min
• 99.99%: 41 L/min
• 99.9%: 90 L/min
• 99.5%: 143 L/min
• 99%: 173 L/min
• 98%: 230 L/min
• 97%: 268 L/min

N2 PICO 4

• 99.999%: 33 L/min
• 99.99%: 55 L/min
• 99.9%: 115 L/min
• 99.5%: 191 L/min
• 99%: 250 L/min
• 98%: 306 L/min
• 97%: 345 L/min

N2 PICO 5

• 99.999%: 38 L/min
• 99.99%: 66 L/min
• 99.9%: 153 L/min
• 99.5%: 240 L/min
• 99%: 306 L/min
• 98%: 383 L/min
• 97%: 441 L/min

N2 PICO 6

• 99.999%: 58 L/min
• 99.99%: 83 L/min
• 99.9%: 173 L/min
• 99.5%: 288 L/min
• 99%: 365 L/min
• 98%: 460 L/min
• 97%: 518 L/min
