Organomation MAXI Nitrogen Generator

The Organomation MAXI (N2 MAXI Series) is a high-capacity industrial nitrogen generator based on PSA Fast Purity technology, designed for applications requiring very high flow rates and stable nitrogen supply.

The system includes an oxygen analyzer and pressure regulator, enabling real-time purity monitoring. Its integrated tank eliminates the need for a buffer vessel, combining storage and delivery in one system.

The generator automatically switches to energy-saving standby mode when production exceeds consumption. An air quality monitoring system (humidity and oil) protects both performance and gas purity.

Full IT integration is enabled via MODBUS, MQTT, and HTTP, with an optional E941 food-grade configuration.

Key Features

• PSA technology (Claind Fast Purity)
• Very high flow rates (up to thousands L/min)
• Real-time nitrogen purity monitoring
• Integrated storage tank (no buffer required)
• Automatic standby mode
• Adjustable purity levels
• Digital control with IT integration
• Air quality protection system
• Unattended continuous operation
• Optional food-grade configuration (E941)

Available Models

• N2 MAXI 1
• N2 MAXI 2
• N2 MAXI 3
• N2 MAXI 4

Standard Features

• PSA nitrogen generator
• Oxygen analyzer
• Pressure regulator
• Digital control system
• Integrated nitrogen tank
• Air quality monitoring system
• Communication interfaces (MODBUS, MQTT, HTTP)

Technical Specifications

General

• Technology: PSA (Fast Purity)
• Dew point: -50 °C
• Output pressure: 1.5 bar below inlet pressure
• Noise: ≤ 60 dB
• Protection class: IP20

Electrical

• 115 / 230 V
• 50–60 Hz
• Power consumption: 50 W

Operating Conditions

• Temperature: 5–40 °C

Air Input Requirements

• Pressure: 6.5–13 bar
• Quality: ISO 8573-1 Class 1.4.1
• Dry, clean, oil-free air

Dimensions

• Height: 207.5 cm
• Depth: 117 cm
• Width:
  • MAXI 1: 62 cm
  • MAXI 2: 103 cm
  • MAXI 3: 142 cm
  • MAXI 4: 182 cm

Weight

• MAXI 1: 730 kg
• MAXI 2: 1400 kg
• MAXI 3: 2050 kg
• MAXI 4: 2700 kg

Performance vs Purity (L/min at 8.5 bar, 20 °C)

N2 MAXI 1

• 99.999%: 103 L/min
• 99.99%: 150 L/min
• 99.9%: 311 L/min
• 99.5%: 518 L/min
• 99%: 651 L/min
• 98%: 828 L/min
• 97%: 931 L/min

N2 MAXI 2

• 99.999%: 206 L/min
• 99.99%: 300 L/min
• 99.9%: 623 L/min
• 99.5%: 1,035 L/min
• 99%: 1,311 L/min
• 98%: 1,648 L/min
• 97%: 1,850 L/min

N2 MAXI 3

• 99.999%: 310 L/min
• 99.99%: 450 L/min
• 99.9%: 935 L/min
• 99.5%: 1,553 L/min
• 99%: 1,965 L/min
• 98%: 2,483 L/min
• 97%: 2,780 L/min

N2 MAXI 4

• 99.999%: 413 L/min
• 99.99%: 600 L/min
• 99.9%: 1,246 L/min
• 99.5%: 2,070 L/min
