Organomation 80 Position MULTIVAP Nitrogen Evaporator

The 80 position MULTIVAP parallel evaporator is a high temperature dry block model. This instrument contains a rectangular gas distribution system mounted on a frame and dual post assembly.

The 80 position MULTIVAP parallel evaporator is a high temperature dry block model. This instrument contains a rectangular gas distribution system mounted on a frame and dual post assembly. The manifold delivers nitrogen gas to the needles or glass pipettes, which direct the gas onto the sample’s surface. This method results in rapid solvent evaporation and sample concentration. In order to conserve nitrogen gas, the manifold has a toggle switch for every row of 8 samples, which allows individual rows to be shut off when evaporating batches of less than 80 samples. Nitrogen gas flow is also controlled by an adjustable flow meter and a built-in pressure regulator.The 80 position MULTIVAP small vial evaporator uses a heated aluminum dry block to reach evaporative temperatures ranging from 30°C to 120°C. An unheated version is available for evaporations that will be performed at ambient temperatures. Sample blocks are customized, within a range of 10-17 mm, for the user’s sample size for maximum and even heat transfer.Since the heat block is made-to-order, we will request that you deliver us three sample vials for each unique vial size upon placing an order for a 30, 48 or 80 Position MULTIVAP. In situations where shipping sample vials to Organomation is not possible, we need precise measurements of your sample vials to be taken.All models can withstand contact with organic solvents; however acid resistant models are also available for use with corrosive solutions.<ul><li>Capacity: Evaporate batches of up to 80 samples at once, with outside diameters of up to 17 mm</li><li>Precise: Digital controls allow exact temperature regulation</li><li>Cost-Effective: Conserve gas by using ON/OFF valve for rows not in use</li><li>Consistent: Uniform evaporation across all samples with no adjustment needed between runs</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Organomation_80_Position_MULTIVAP_Nitrogen_Evaporator_2_8d7053713b.jpg" alt="Organomation 80 Position MULTIVAP Nitrogen Evaporator." srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Organomation_80_Position_MULTIVAP_Nitrogen_Evaporator_2_8d7053713b.jpg 156w," sizes="100vw" width="1400" height="1400"><h3>STANDARD FEATURES</h3><ul><li>Adjustable flow meter, 0-25 lpm</li><li>Dual band hoist spring assembly</li><li>High temperature limit switch for safety</li><li>Safety control cover plate</li><li>Digital temperature controller</li><li>Electronic timer</li><li>Nitrogen filter</li><li>Gas distribution manifold</li><li>Built-in pressure reducing regulator</li><li>Needle guide</li></ul><h3>OPTIONS&nbsp;</h3><ul><li>220v wiring harness (Option Code# -2), Cat# 11880-2</li><li>Z-Purge/positive pressure purge case (Option Code# -Z), Cat# 11880-Z</li><li>Acid resistant coating on instrument and needles (Option Code# -RT), Cat# 11880-RT</li><li>Pasteur pipette adapters in place of needles (Option Code -P), Cat# 11880-P</li><li>Manifold and stand only: no heating platform (Option Code -O), Cat# 11880-O</li></ul><h3>SPECS</h3><h4>80 Position MULTIVAP (Dry Block)</h4><ul><li>Heater Type: Dry Block</li><li>Instrumental Catalog Number: 11880</li><li>Number of Sample Positions: 80</li><li>Overall Dimension (w × d × h): 16 × 14 × 30 in / 41 × 36 × 76 cm</li><li>Sample Holder Layout: Rectangular</li><li>Gas Manifold Layout: 8 × 10 Array</li><li>Center to Center Spacing Between Positions: 0.8 in / 2.03 cm</li><li>Test Tube Diameter: 10–17 mm OD</li><li>Gas Flow Control On/Off Valve: Every row of 8</li><li>Stainless Steel Needles (Length × Gauge): 4.0 in × 19 ga / 102 mm × 19 ga</li><li>Needle Guide: Standard</li><li>Hoist Assembly: Dual Pulley &amp; Band Springs</li><li>Integrated Control Box with Timer for Nitrogen &amp; Heat: Standard</li><li>Built-in Gas Regulator Input: 30–110 psig</li><li>Acid Resistant Coating (Option Code -RT): Optional</li></ul><h5>OA-SYS Heating Device Specifications</h5><ul><li>Model Number: 9156</li><li>Outside Dimensions: 16 × 14 × 6.5 in / 41 × 36 × 15 cm</li><li>Total Wattage: 900 W</li><li>Temperature Range: 30–120 °C</li><li>Temperature Controller Type: Digital Electronic with LED Display</li><li>Controller Accuracy: ±2 °C</li></ul><h4>80 Position MULTIVAP (No Heater)</h4><ul><li>Heater Type: None</li><li>Instrumental Catalog Number: 11880-O</li><li>Number of Sample Positions: 80</li><li>Overall Dimension (w × d × h): 13 × 15 × 26 in / 33 × 38 × 66 cm</li><li>Sample Holder Layout: Rectangular</li><li>Gas Manifold Layout: 8 × 10 Array</li><li>Center to Center Spacing Between Positions: 0.8 in / 2.03 cm</li><li>Test Tube Diameter: 10–17 mm OD</li><li>Gas Flow Control On/Off Valve: Every row of 8</li><li>Stainless Steel Needles (Length × Gauge): 4.0 in × 19 ga / 102 mm × 19 ga</li><li>Needle Guide: Standard</li><li>Hoist Assembly: Dual Pulley &amp; Band Springs</li><li>Integrated Control Box with Timer for Nitrogen &amp; Heat: N/A</li><li>Built-in Gas Regulator Input: 30–110 psig</li><li>Acid Resistant Coating (Option Code -RT): Optional</li></ul><h3>ACCESSORIES</h3><ul><li>Custom sized inserts (cat# NA1881, cat# NA1882)</li><li>Pasteur pipette adapters (cat# NA0636, cannot be used with needle guide)</li><li>Luer plugs (cat# NA1307)</li><li>Pressure reducing regulator 0-160 psi (cat# NA0630)</li><li>Various needle sizes and gauges</li></ul>

Organomation RapidVap N2 Nitrogen Evaporator

The RapidVap N₂ nitrogen evaporator enables fast solvent evaporation using a controlled nitrogen stream. It combines dry block heating, vortex motion, and end-point detection for efficient sample concentration.

The RapidVap N₂ Evaporation Systems provide a fast, automated alternative to <a target="_blank" rel="noopener noreferrer" href="https://lcms.labrulez.com/products/1904">Kuderna-Danish</a> and rotary evaporators, compatible with a wide range of aggressive chemicals. By directing a controlled stream of nitrogen or dry gas onto the sample surface, these systems reduce the partial pressure above the liquid to accelerate evaporation, with optional vortex motion and dry heat for further speed.&nbsp;The main block accommodates eight large samples up to 450 mL each, and an accessory block supports eight 170 mL tubes for solid phase extraction.&nbsp;The unique Cool-Zone block design slows evaporation after the end point, preventing samples from going completely dry and allowing time for solvent exchange or removal. Built-in alarms notify users when the process reaches the timed end point or approaches completion, enabling unattended operation.&nbsp;<ul><li>Dry Block: Dry heating system prevents potential contamination source</li><li>Increased Surface Area: Vortex motion increases surface area for faster evaporation</li><li>PTFE-Coated Chamber: Aluminum with PTFE coating for broad range of chemical compatibility</li><li>End-Point Detection: Signal completion of run allows samples to be left unattended while drying to desired end point</li></ul>In partnership with Labconco.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Organomation_Rapid_Vap_N2_Nitrogen_Evaporator_2_eb75d729d4.jpg" alt="Organomation RapidVap N2 Nitrogen Evaporator " srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Organomation_Rapid_Vap_N2_Nitrogen_Evaporator_2_eb75d729d4.jpg 235w," sizes="100vw" width="1152" height="764"><h3>STANDARD FEATURES</h3><ul><li>Dry block heating system prevents adding potential contamination source</li><li>Vortex action, heat, and vacuum combine to accelerate evaporation</li><li>PTFE-coated chamber for broad range of chemical compatibility</li><li>Microprocessor-controlled vortex motion increases surface area for faster evaporation</li><li>Signal completion of run allows samples to be left unattended while evaporation to desired end point</li><li>Microprocessor-controlled nitrogen blow down manifold to facilitate liquid to gas phase change</li></ul><h3>REQUIREMENTS (not included):</h3><ul><li>Glassware</li><li>Nitrogen source with flow rate of 0.6 CFM/17 LPM minimu</li><li>Gas pressure regulator</li></ul><h3>OPTIONS</h3><ul><li>RS-232 Link for two-way communication (Cat# LC-7910010)</li></ul><h3>SPECIFICATIONS</h3><ul><li>Instrument: RapidVap N2</li><li>Instrument Catalog Number: LC-7910000</li><li>Bath Type: Dry aluminum blocks</li><li>Number of Sample Positions: Up to 8</li><li>Dimensions (w x d x h): 21.7 x 19.0 x 13.5 in</li><li>Weight: Net: 99 lbs. (45 kg)</li><li>Weight: Gross: 107 lbs. (49 kg)</li><li>Sample Layout: Circular</li><li>Lid Material: Glass</li><li>Pressure Regulator: 0–20 psi</li><li>Temperature Range: 0–100 °C</li><li>Warranty: 1 year</li><li>Electrical Requirements: 115V, 60 Hz</li><li>Vortex Motion: Up to 500 RPM</li></ul><h5>Nitrogen Requirements</h5><ul><li>Flow Rate: 0.6 CFM / 17 LPM minimum</li><li>Pressure: 5–10 psi</li></ul><h3>ACCESSORIES</h3><ul><li>PTFE-coated aluminum blocks</li><li>Borosilicate glass tubes</li><li>600 mL tubes with stems</li><li>170 mL tubes with stems</li><li>Flat bottom tubes</li><li>Eight-place stainless steel racks</li><li>Glassware caps</li></ul>

Organomation RapidVap N2/48 Nitrogen Evaporator

The RapidVap N₂/48 Nitrogen Evaporation System rapidly concentrates up to 48 samples using nitrogen blowdown, vortex motion, and dry block heating without the need for water baths.

The RapidVap N₂/48 Evaporation System combines nitrogen blowdown, vortex motion, and controlled heat to accelerate evaporation of up to 48 small samples or eight 450 mL samples simultaneously. A stream of nitrogen or dry gas reduces the partial pressure over the liquid, speeding solvent removal, while microprocessor-controlled vortex motion increases surface area and continuously mixes samples for maximum recovery.&nbsp;Nitrogen delivery can be applied to 2, 4, 6, or all 8 clusters of six ports, conserving gas when processing fewer samples. Using a dry block heating method, the RapidVap N₂/48 offers a reliable, low-maintenance alternative to water bath systems and is ideal for applications such as drug development, bioresearch, combinatorial chemistry, environmental testing, forensics, and toxicology.&nbsp;<ul><li>Dry Block: Dry heating system prevents potential contamination source</li><li>Increased Surface Area: Vortex motion increases surface area for faster evaporation</li><li>PTFE-Coated Chamber: Aluminum with PTFE coating for broad range of chemical compatibility</li><li>End-Point Detection: Signal completion of run allows samples to be left unattended while drying to desired end point</li></ul>In partnership with Labconco.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Organomation_Rapid_Vap_N2_48_Nitrogen_Evaporator_2_cc454a8f2d.jpg" alt="Organomation RapidVap N2_48 Nitrogen Evaporator" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Organomation_Rapid_Vap_N2_48_Nitrogen_Evaporator_2_cc454a8f2d.jpg 234w," sizes="100vw" width="1169" height="783"><h3>STANDARD FEATURES</h3><ul><li>Dry block heating system prevents adding potential contamination source</li><li>Vortex action, heat, and vacuum combine to accelerate evaporation</li><li>PTFE-coated chamber for broad range of chemical compatibility</li><li>Microprocessor-controlled vortex motion increases surface area for faster evaporation</li><li>Signal completion of run allows samples to be left unattended while evaporation to desired end point</li><li>Microprocessor-controlled nitrogen blow down manifold to facilitate liquid to gas phase change</li></ul><h3>REQUIREMENTS (not included)</h3><ul><li>Sample block</li><li>Glassware</li><li>Nitrogen source with flow rate of 3.5 CFM/100 LPM minimu</li><li>Gas pressure regulator</li></ul><h3>OPTIONS</h3><ul><li>RS-232 Link for two-way communication (Cat# LC-7910014)</li></ul><h3>SPECIFICATIONS</h3><ul><li>Instrument: RapidVap N2/48</li><li>Instrument Catalog Number: LC-7910012</li><li>Bath Type: Dry aluminum blocks</li><li>Number of Sample Positions: Up to 48</li><li>Dimensions (w x d x h): 21.7 x 19.0 x 13.5 in</li><li>Weight: Net: 92 lbs. (42 kg)</li><li>Weight: Gross: 100 lbs. (45 kg)</li><li>Sample Layout: Circular</li><li>Lid Material: Glass</li><li>Pressure Regulator: 0–20 psi</li><li>Temperature Range: 0–100 °C</li><li>Warranty: 1 year</li><li>Electrical Requirements: 115V, 60 Hz</li><li>Vortex Motion: Up to 500 RPM</li></ul><h5>Nitrogen Requirements</h5><ul><li>Flow Rate: 3,5 CFM / 100 LPM minimum</li><li>Pressure: 5–10 psi</li></ul><h3>ACCESSORIES</h3><ul><li>PTFE-coated aluminum blocks</li><li>Borosilicate glass tubes</li><li>600 mL tubes with stems</li><li>170 mL tubes with stems</li><li>Flat bottom tubes</li><li>Eight-place stainless steel racks</li><li>Glassware caps</li></ul>

Organomation RapidVap Vertex Dry Evaporator

The RapidVap Vertex dry evaporator accelerates solvent evaporation for up to 50 samples using dry block heating, gentle nitrogen blowdown, and an intuitive touchscreen interface.

The RapidVap Vertex Dry Evaporator accelerates sample evaporation by combining efficient dry heat with gentle nitrogen blowdown, allowing laboratories to process up to 50 samples simultaneously.Its intuitive touchpad interface makes it easy to set and control both temperature and run time, and users can save up to ten custom programs to ensure consistent, repeatable workflows. Because it relies on a dry block heater rather than a traditional water bath, the system requires minimal upkeep—no distilled water, additives, or concerns about waterborne contamination.The RapidVap Vertex is well-suited for a wide range of sample prep needs, including pharmaceutical and drug development, clinical laboratories, environmental analysis, agricultural chemistry, and forensic testing.&nbsp;<ul><li>LCD Display: Touchscreen programming shows parameters for block, sample, and time</li><li>Nitrogen Control: Each switch controls nitrogen flow to each row of five nozzles</li><li>Temperature Sensor: Monitors block or sample temperature</li><li>Dry heat - no water bath: Less maintenance, no rust, no condensation, and no potential source of cross contamination</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Organomation_Rapid_Vap_Vertex_Dry_Evaporator_2_c112725d7a.jpg" alt="Organomation RapidVap Vertex Dry Evaporator" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Organomation_Rapid_Vap_Vertex_Dry_Evaporator_2_c112725d7a.jpg 245w," sizes="100vw" width="1375" height="768">In partnership with Labconco.<h3>STANDARD FEATURES</h3><ul><li>LCD display with touchscreen programming</li><li>Nitrogen control to each row of nozzles</li><li>Pressure regulator for 0 to 45 psi</li><li>Dry heat for less maintenance and no rust compared to water baths</li><li>Microprocessor-controlled heater up to 100 °C</li><li>Temperature sensor monitors block or sample temperature</li><li>Angled samples to increase surface area for faster evaporation</li></ul><h3>REQUIREMENTS (not included)</h3><ul><li>Aluminum block (Specific cat # depends on your tube size)</li><li>Sample tubes</li><li>Nitrogen source with a flow rate of 6.5 CFM/185 LPM minimum</li></ul><h3>SPECIFICATIONS</h3><ul><li>Instrument Catalog Number: LC-7320020</li><li>Bath Type: Dry aluminum blocks</li><li>Number of Sample Positions: Up to 50</li><li>Dimensions (w x d x h): 20.4 x 13.0 x 12.5 in</li><li>Weight: Net: 35 lbs. (16 kg)</li><li>Weight: Gross: 45 lbs. (20 kg)</li><li>Sample Layout: 5 rows of 10 samples</li><li>Lid Material: Glass</li><li>Pressure Regulator: 0–45 psi</li><li>Temperature Range: 30–100 °C</li><li>Warranty: 1 year</li><li>Electrical Requirements: 115V, 60 Hz</li></ul><h5>Nitrogen Requirements</h5><ul><li>Flow Rate: 6.5 CFM / 185 LPM minimum</li><li>Pressure: &lt;50 psi</li></ul><h3>ACCESSORIES</h3><ul><li>Aluminum blocks</li></ul>

Organomation 6 Position N-EVAP Nitrogen Evaporator

Compact nitrogen evaporator for up to 6 samples with precise flow control, heated bath options, and wide sample compatibility.

The Organomation 6 Position N-EVAP is a compact and cost-effective sample concentrator designed for simultaneous evaporation of up to 6 samples. Based on the proven N-EVAP technology developed in the 1970s, it ensures reliable and reproducible solvent evaporation using nitrogen gas within a heated bath.The system supports a wide range of sample sizes – 10–30 mm OD as standard, and up to 30–56 mm OD with an optional holder. The circular rotating design allows easy front access to all samples.<h4>Key Features</h4><ul><li>Evaporation of up to 6 samples simultaneously</li><li>Adjustable nitrogen flow: 0–10 L/min</li><li>Individually adjustable needle valves for precise control</li><li>Circular rotating sample holder for easy access</li><li>Wide sample diameter range: 10–56 mm OD (with optional holder)</li><li>Stainless steel bath construction for durability</li><li>Water or dry bath configurations available</li><li>High temperature limit switch for safety</li><li>Phthalate-free silicone tubing to prevent contamination</li><li>Efficient nitrogen usage with minimal waste</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 6</li><li>Sample holder layout: Circular</li><li>Gas manifold: Single ring</li><li>Gas flow meter: 0–10 L/min</li><li>Standard sample OD: 10–30 mm</li><li>Optional sample OD: 30–56 mm</li><li>Gas input pressure: 20–30 psig</li><li>With regulator: 30–160 psig</li></ul><h4>Dimensions</h4><ul><li>Water bath: 33 × 28 × 79 cm</li><li>Dry bath: 33 × 28 × 70 cm</li><li>Reduced height: 33 × 28 × 61 cm</li></ul><h4>Needles</h4><ul><li>Length: 4 in (≈10 cm)</li><li>Gauge: 19 ga</li><li>Material: stainless steel + chrome-plated brass hub</li></ul><h4>Heating – Water Bath</h4><ul><li>Temperature range: 30–90 °C</li><li>Power: 550 W</li><li>Controller: mechanical thermostat</li><li>Accuracy: ±2 °C</li></ul><h4>Heating – Dry Bath</h4><ul><li>Temperature range: 40–130 °C</li><li>Power: 500 W</li><li>Medium: aluminum / glass beads</li><li>Accuracy: ±2 °C</li></ul>

Organomation 20 Position Auto N-EVAP Nitrogen Evaporator

The 20 Position Auto N-EVAP enables automated, safe evaporation of up to 20 samples with digital control and pneumatic sample handling.

The Organomation 20 Position Auto N-EVAP is the most advanced nitrogen evaporator developed by Organomation. It combines the classic N-EVAP system with timed automation and optional nitrogen self-generation.The instrument operates in both automatic and manual modes using an integrated pneumatic system. In automatic mode, samples are removed from the heating bath at the end of the cycle, reducing the risk of sample loss or damage.A digital control system provides precise control of gas flow and bath temperature, ensuring safe and reproducible evaporation of up to 20 samples simultaneously.<h4>Key Features</h4><ul><li>Automatic and manual operation modes</li><li>Capacity of up to 20 samples</li><li>Automatic sample removal after cycle completion</li><li>Digital control of temperature and timing</li><li>Nitrogen flow up to 25 L/min</li><li>Built-in pressure reducing regulator</li><li>Dual nitrogen filtration system</li><li>Pneumatic sample lift (gas piston)</li><li>Safety cover and circuit breaker</li><li>Precision needle valve control</li><li>Phthalate-free high-pressure tubing</li><li>Reduced risk of sample loss through automation</li></ul><h4>Available Model</h4><h5>Automatic 20 Position N-EVAP – Water Bath</h5><ul><li>Catalog number: 11220-A</li><li>Bath type: Water</li><li>Number of positions: 20</li><li>Dimensions: 49 × 46 × 92 cm</li><li>Temperature range: 30–100 °C</li><li>Total wattage: 1100 W</li></ul><h5>Standard Features</h5><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Built-in pressure reducing regulator</li><li>Dual nitrogen filters</li><li>Digital temperature controller (LED)</li><li>Electronic timer</li><li>High temperature limit switch</li><li>Safety cover</li><li>Circuit breaker</li><li>High-pressure phthalate-free tubing</li><li>Precision variable valve technology</li><li>Gas piston lift mechanism</li><li>Set of 20 needles (4" × 19 gauge)</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating on instrument and needles</li></ul><h4>Technical Specifications</h4><h4>General</h4><ul><li>Number of positions: 20</li><li>Sample holder layout: Circular</li><li>Gas manifold: Single Ring</li><li>Gas flow rate: 0–25 L/min</li><li>Sample size range: 10–30 mm OD</li><li>Nitrogen input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 19 ga (4")</li><li>Material: stainless steel with plated brass hub</li></ul><h4>Sample Lift Mechanism</h4><ul><li>Type: Gas piston</li><li>Function: automatic lifting/removal of samples</li></ul><h4>Control System</h4><ul><li>Digital temperature control (LED display)</li><li>Electronic timer for gas and heating</li></ul><h4>Heating Specifications</h4><ul><li>Model: 11196</li><li>Medium: Water</li><li>Inside dimensions: 11 × 11 × 5.5 in</li><li>Outside dimensions: 49 × 46 × 18 cm</li><li>Power: 1100 W</li><li>Temperature range: 30–100 °C</li><li>Controller: digital electronic</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator (20 L/min)</li><li>Pasteur pipette adapters</li><li>Pressure reducing regulator 0–160 psi</li><li>High temperature silicone fluid</li><li>Various needle sizes and gauges</li></ul><h4>Replacement Parts</h4><ul><li>NA1955 – Nitrogen generator</li><li>NA0603 – Needles 4" × 19 ga</li><li>NA0636 – Pasteur pipette adapter</li></ul>

Organomation 9 Position MULTIVAP Nitrogen Evaporator

The MULTIVAP 9 Position enables rapid evaporation of large-volume samples using a high-temperature dry block and efficient row-based nitrogen control.

The Organomation 9 Position MULTIVAP is a high-temperature dry block nitrogen evaporator designed for large volume sample evaporation.The system features a rectangular 3×3 gas distribution manifold and a dual post lifting assembly, allowing easy adjustment of needles or pipettes. Nitrogen is directed onto the sample surface, enabling rapid solvent evaporation and efficient sample concentration.Each row of three positions can be individually switched on/off, allowing significant nitrogen savings when processing fewer samples.The system operates with a heated aluminum dry block (30–120 °C) or as an ambient (unheated) version.<h4>Key Features</h4><ul><li>Up to 9 samples simultaneously (3×3 layout)</li><li>High-temperature dry block: 30–120 °C</li><li>Ambient (unheated) version available</li><li>Direct nitrogen delivery onto sample surface</li><li>Row-based gas control (3 samples per row)</li><li>Nitrogen flow range: 0–25 L/min</li><li>Built-in pressure regulator</li><li>Digital temperature control and timer</li><li>Dual spring hoist lifting system</li><li>Includes 50 mm OD beakers</li><li>Custom inserts available for different sample sizes</li><li>Compatible with organic solvents</li><li>Optional acid-resistant configuration</li></ul><h4>Available Models</h4><h5>9 Position MULTIVAP – Dry Block</h5><ul><li>Catalog number: 11809</li><li>Heating type: Dry block</li><li>Number of positions: 9</li><li>Dimensions: 41 × 36 × 76 cm</li><li>Temperature range: 30–120 °C</li><li>Power: 900 W</li></ul><h5>9 Position MULTIVAP – No Heating</h5><ul><li>Catalog number: 11809-O</li><li>Heating type: None</li><li>Number of positions: 9</li><li>Dimensions: 33 × 38 × 66 cm</li><li>Temperature: Ambient</li></ul><h4>Standard Features</h4><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Gas distribution manifold (3×3)</li><li>Nitrogen filter</li><li>Built-in pressure reducing regulator</li><li>Electronic timer</li><li>Digital temperature controller (LED)</li><li>Safety control cover plate</li><li>High temperature limit switch</li><li>Dual band hoist spring assembly</li><li>9 beakers (50 mm OD included)</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating</li><li>Pasteur pipette adapters instead of needles</li><li>Manifold and stand only (no heating platform)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 9</li><li>Layout: Rectangular (3×3)</li><li>Spacing: 5.87 cm</li><li>Standard vessels: 50 mm OD beakers</li><li>Optional tube range: 16–40 mm OD</li><li>Gas flow: 0–25 L/min</li><li>Flow control: per row (3 samples)</li><li>Gas input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 16 ga</li><li>Material: stainless steel</li><li>Needle guide: optional for tubes</li></ul><h4>Lift Mechanism</h4><ul><li>Type: Dual pulley &amp; band springs</li><li>Function: adjustable needle height</li></ul><h4>Heating Specifications</h4><ul><li>Model: 9156</li><li>Type: Aluminum dry block</li><li>Dimensions: 41 × 36 × 15 cm</li><li>Power: 900 W</li><li>Temperature range: 30–120 °C</li><li>Controller: digital electronic (LED)</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator</li><li>Custom inserts&nbsp;</li><li>Pasteur pipette adapters</li><li>Luer plugs</li><li>Various needle sizes and gauges</li></ul>

Organomation 30 Position MULTIVAP Nitrogen Evaporator

The MULTIVAP 30 Position enables high-throughput evaporation of up to 30 samples with a heated dry block, efficient gas control, and custom inserts.

The Organomation 30 Position MULTIVAP is a high-capacity dry block nitrogen evaporator designed for parallel evaporation of up to 30 samples.The system features a rectangular 5×6 gas distribution manifold and a dual post lifting assembly. Nitrogen is directed onto the sample surface, enabling rapid solvent evaporation and efficient concentration.Each row of 5 samples can be independently switched on/off, allowing significant nitrogen savings when processing fewer samples.The system operates with a heated aluminum dry block (30–120 °C) or as an ambient (unheated) version. Custom-made inserts and blocks ensure optimal heat transfer for specific sample sizes.<h4>Key Features</h4><ul><li>Up to 30 samples simultaneously (5×6 layout)</li><li>High-temperature dry block: 30–120 °C</li><li>Ambient (no heating) version available</li><li>Direct nitrogen blowdown onto sample surface</li><li>Row-based gas control (5 samples per row)</li><li>Nitrogen flow: 0–25 L/min</li><li>Built-in pressure regulator</li><li>Digital temperature control and timer</li><li>Dual spring hoist system</li><li>Custom inserts for optimized heat transfer</li><li>Compatible with organic solvents</li><li>Optional acid-resistant version</li></ul><h4>Available Models</h4><h5>30 Position MULTIVAP – Dry Block</h5><ul><li>Catalog number: 11830</li><li>Heating type: Dry block</li><li>Number of positions: 30</li><li>Dimensions: 41 × 36 × 76 cm</li><li>Temperature range: 30–120 °C</li><li>Power: 900 W</li></ul><h5>30 Position MULTIVAP – No Heating</h5><ul><li>Catalog number: 11830-O</li><li>Heating type: None</li><li>Number of positions: 30</li><li>Dimensions: 33 × 38 × 66 cm</li><li>Temperature: Ambient</li></ul><h4>Standard Features</h4><ul><li>Adjustable flow meter: 0–25 L/min</li><li>Gas distribution manifold (5×6)</li><li>Nitrogen filter</li><li>Built-in pressure reducing regulator</li><li>Digital temperature controller (LED)</li><li>Electronic timer</li><li>Safety control cover plate</li><li>High temperature limit switch</li><li>Dual band hoist spring assembly</li></ul><h4>Options</h4><ul><li>220v wiring harness</li><li>Z-Purge / positive pressure purge case</li><li>Acid resistant coating</li><li>Pasteur pipette adapters instead of needles</li><li>Manifold and stand only (no heating platform)</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Number of positions: 30</li><li>Layout: Rectangular (5×6)</li><li>Spacing: 3.33 cm</li><li>Sample diameter range: 16–30 mm OD</li><li>Gas flow: 0–25 L/min</li><li>Flow control: per row (5 samples)</li><li>Gas input pressure: 30–110 psig</li><li>Acid resistant coating: Optional</li></ul><h4>Needles</h4><ul><li>Size: 102 mm × 19 ga</li><li>Material: stainless steel</li><li>Needle guide: optional</li></ul><h4>Lift Mechanism</h4><ul><li>Type: Dual pulley &amp; band springs</li><li>Function: adjustable needle height</li></ul><h4>Heating Specifications</h4><ul><li>Model: 9156</li><li>Type: Aluminum dry block</li><li>Dimensions: 41 × 36 × 15 cm</li><li>Power: 900 W</li><li>Temperature range: 30–120 °C</li><li>Controller: digital electronic (LED)</li><li>Accuracy: ±2 °C</li></ul><h4>Accessories</h4><ul><li>Nitrogen generator</li><li>Custom inserts</li><li>Pasteur pipette adapters (not compatible with needle guide)</li><li>Luer plugs</li><li>Various needle sizes and gauges</li></ul>

Organomation H Series Hydrogen Generator

The H Series Hydrogen Generator delivers up to 600 mL/min hydrogen with 99.9999% purity, advanced safety features, and scalable modular design.

The Organomation H Series Hydrogen Generator is a modular hydrogen generation system designed for GC, GC-MS (GC-MSD), and FAST GC applications. It is available in three models with flow rates of 200, 400, and 600 mL/min, delivering ultra-high purity hydrogen up to 99.9999%.The system uses HT PEM electrolytic cell technology, producing hydrogen on demand, minimizing internal gas storage and enhancing safety.A comprehensive safety system includes acoustic alarms, display messages, and automatic shutdown in case of gas leaks, with automatic switching to inert gas if hydrogen production stops.The generator features a touchscreen CPU, supports CAN-BUS and LAN connectivity, and allows real-time monitoring, diagnostics, and maintenance management. Up to four units can be connected in parallel for scalable performance.<h4>Key Features</h4><ul><li>Three models: 200 / 400 / 600 mL/min</li><li>Hydrogen purity up to 99.9999% (UHP)</li><li>HT PEM electrolytic cell technology</li><li>On-demand hydrogen production</li><li>Advanced safety system with alarms and auto shutdown</li><li>Automatic switch to inert gas</li><li>Removable water tank for easy maintenance</li><li>Low maintenance and low operating cost</li><li>Parallel connection of up to 4 units</li><li>Touchscreen CPU with CAN-BUS and LAN</li><li>Full monitoring of system status and alarms</li></ul><h4>Available Models</h4><h5>H Series 200</h5><ul><li>Flow rate: 200 mL/min ±10%</li><li>Power consumption: 110 W</li></ul><h5>H Series 400</h5><ul><li>Flow rate: 400 mL/min ±10%</li><li>Power consumption: 180 W</li></ul><h5>H Series 600</h5><ul><li>Flow rate: 600 mL/min ±10%</li><li>Power consumption: 250 W</li></ul><h4>Standard Features</h4><ul><li>HT PEM electrolytic cell</li><li>Touchscreen CPU</li><li>LAN connectivity</li><li>CAN-BUS communication</li><li>Removable water tank</li><li>Automatic water refill pump</li><li>Safety system with alarms and auto shutdown</li><li>Automatic inert gas switching</li><li>Modular stackable configuration</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Technology: HT PEM electrolytic cell</li><li>Purity: 99.9999%</li><li>Oxygen: &lt; 1 ppm</li><li>Dew point: &lt; -70°C</li><li>Output pressure: 2–8 bar (30–116 psi)</li><li>Max altitude: 2000 m</li><li>Noise: &lt; 50 dBA</li><li>Protection class: IP20</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>H200: 110 W</li><li>H400: 180 W</li><li>H600: 250 W</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–35 °C</li><li>Humidity: max 90% non-condensing</li></ul><h4>Water Requirements</h4><ul><li>Minimum resistivity: &gt;1 MΩ·cm (ASTM II)</li><li>Recommended: &lt;10 MΩ·cm (ASTM I)</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 47 × 38 × 53 cm</li><li>Weight: 30 kg</li></ul><h4>Connections</h4><ul><li>Hydrogen output: G 1/8" female (AISI 316)</li><li>Exhaust: 4 mm quick connector</li><li>Water input: 1/4" connection</li></ul><h4>Warranty</h4><ul><li>2 years</li></ul><h4>Accessories</h4><ul><li>Water demineralizer</li><li>Maintenance kit (9,000 / 18,000 hours)</li><li>Water refill pump</li></ul>

Organomation HG 2200 R Hydrogen Generator

The Organomation HG 2200 R delivers up to 200 mL/min hydrogen with >99.999% purity, low noise, and easy maintenance for THC analyzers.

The Organomation HG 2200 R is a compact hydrogen generator designed for THC and emission monitoring analyzers. It delivers flow rates up to 200 mL/min with hydrogen purity greater than 99.999%, and oxygen content below 0.1 ppm when used with additional purifiers.The unit allows adjustable outlet pressure from 1 to 4 bar (up to 6 bar on demand) and features a removable external water tank for easy maintenance. An automatic water loading pump supports continuous operation.<h4>Key Features</h4><ul><li>Hydrogen flow up to 200 mL/min</li><li>Purity &gt;99.999% (UHP)</li><li>O₂ &lt;0.1 ppm with additional purifier</li><li>Adjustable outlet pressure: 1–4 bar (up to 6 bar)</li><li>Removable water tank for easy cleaning</li><li>Optional continuous water supply (pump)</li><li>Low noise level &lt;46 dB</li><li>Compact benchtop design</li><li>Simple operation and maintenance</li></ul><h4>Standard Features</h4><ul><li>UHP hydrogen generation (&gt;99.999%)</li><li>Pressure control via keyboard</li><li>Removable water tank</li><li>External water supply capability</li><li>Integrated dryer with molecular sieve</li></ul><h3>Technical Specifications</h3><h4>General</h4><ul><li>Model: HG 2200 R</li><li>Flow rate: 200 mL/min</li><li>Purity: &gt;99.999%</li><li>Oxygen content: &lt;0.1 ppm (with purifier)</li></ul><h4>Output Pressure</h4><ul><li>Standard: 1–4 bar</li><li>Maximum: 6 bar (on request)</li></ul><h4>Electrical</h4><ul><li>115/230 V, 50–60 Hz</li><li>Power rating: 100 VA</li></ul><h4>Operating Conditions</h4><ul><li>Temperature: 5–40 °C</li><li>Noise level: &lt;46 dB</li></ul><h4>Water Requirements</h4><ul><li>Demineralized water ≤ 5 µS/cm (~0.2 MΩ·cm)</li></ul><h4>Consumables</h4><ul><li>Dryer with molecular sieve</li></ul><h4>Dimensions &amp; Weight</h4><ul><li>Dimensions: 31 × 48 × 38 cm</li><li>Weight: 20 kg</li></ul><h4>Warranty</h4><ul><li>1 year</li></ul><h4>Accessories / Options</h4><ul><li>Additional purifiers for ultra-low O₂</li><li>Water refill pump</li></ul>
