Organomation 6 Position N-EVAP Nitrogen Evaporator

The Organomation 6 Position N-EVAP is a compact and cost-effective sample concentrator designed for simultaneous evaporation of up to 6 samples. Based on the proven N-EVAP technology developed in the 1970s, it ensures reliable and reproducible solvent evaporation using nitrogen gas within a heated bath.

The system supports a wide range of sample sizes – 10–30 mm OD as standard, and up to 30–56 mm OD with an optional holder. The circular rotating design allows easy front access to all samples.

Key Features

• Evaporation of up to 6 samples simultaneously
• Adjustable nitrogen flow: 0–10 L/min
• Individually adjustable needle valves for precise control
• Circular rotating sample holder for easy access
• Wide sample diameter range: 10–56 mm OD (with optional holder)
• Stainless steel bath construction for durability
• Water or dry bath configurations available
• High temperature limit switch for safety
• Phthalate-free silicone tubing to prevent contamination
• Efficient nitrogen usage with minimal waste

Technical Specifications

General

• Number of positions: 6
• Sample holder layout: Circular
• Gas manifold: Single ring
• Gas flow meter: 0–10 L/min
• Standard sample OD: 10–30 mm
• Optional sample OD: 30–56 mm
• Gas input pressure: 20–30 psig
• With regulator: 30–160 psig

Dimensions

• Water bath: 33 × 28 × 79 cm
• Dry bath: 33 × 28 × 70 cm
• Reduced height: 33 × 28 × 61 cm

Needles

• Length: 4 in (≈10 cm)
• Gauge: 19 ga
• Material: stainless steel + chrome-plated brass hub

Heating – Water Bath

• Temperature range: 30–90 °C
• Power: 550 W
• Controller: mechanical thermostat
• Accuracy: ±2 °C

Heating – Dry Bath

• Temperature range: 40–130 °C
• Power: 500 W
• Medium: aluminum / glass beads
• Accuracy: ±2 °C
