<h3>Training Scenarios</h3>
Also in reality for GC &amp; GC/MS training most trainees are at completely different levels of ability and experience in relation to aspects of the technique, instruments, software.
In addition, certain industries and markets have unique instrument techniques, configurations and applications that require different knowledge that a general GC analyst may have no or at best, limited experience in that area.
<h3>Traditional Training</h3>
Traditional training often occurs sporadically and is usually attending off site with traditional lectures and presentations.
As there are a wide range of GC &amp; GC/MS sample preparation techniques, injectors, columns, detectors and software often you just get a overall simple overview of the theory behind each with limited hands on experience or time to ask questions.
You will probably have to attend a separate courses for troubleshooting, software or method development. This is basically logistically impossible to achieve when attending separate generic courses from different training providers attempting to cover attendees from different companies and areas of interest.
What is really required is a bespoke detailed program around your instrument, application/market segment and most importantly the individual(s). Also, there is a logical optimal scheduled timing and pathway to increase your relative productivity.
<h3>New Remote Options Available</h3>
<h5>The advantages of remote learning are:</h5>
<ul>
<li>Training periods can be shorter and more effective </li>
<li>Time to implement learning between training sessions </li>
<li>Bespoke to your instrument configuration and software version </li>
<li>No access arrangements to site are required </li>
<li>No health &amp; safety/Covid, issues to deal with. </li>
<li>Lower cost</li>
</ul>
There are disadvantages such as unfounded IT fears (typically in larger organizations) and the personal interaction is not quite the same however as the training is carried out remotely with a maximum of 4 people, the impact is minimal compared with the advantages. However there are few companies supplying a cost effective bespoke training solutions and services around your specific situation.
<h5>Two of the most common situations at each end of the training spectrum are listed below:</h5>
<ul>
<li>Replacement staff: Basic software training </li>
<li>Instrument installation with new staff: Specific theory around the instrument configuration, method development/translation, maintenance information, troubleshooting, data processing and reporting.</li>
</ul>
<h3>Conclusion</h3>
The best approach is a training schedule could cover either theory, specific instrument, software and application or combines some or all of these areas. It should also take into account the trainees experience to tailor the training program to realistic small manageable training periods (typically 2-4 hours). ChromSolutions can offer this bespoke service through their remote support program. We have not only trained customer, we have also trained sales and administration personnel.
<h3><a href="http://www.chromsolutions.co.uk/">ChromSolutions Ltd</a></h3>
What we offer at ChromSolutions is our wealth of experience in analytical instrument sales and support (over 110 years distributed through the members of our company). We can help you from defining your requirements to the implementation of a robust gas analytical method fit for purpose.

GC & GC/MS Training Quick Reference Guide

The issues from converting from helium to hydrogen are:
<ul>
<li>Safety</li>
<li>Instrument modifications</li>
<li>Method changes (particularly within regulatory compliance industries)</li>
<li>Time to develop/revalidate a method</li>
<li>Knowledge and persons/company to perform the change</li>
</ul>
<h3>Safety</h3>
If you want to use hydrogen and do not have a supply in the laboratory with the appropriate safety, we would recommend a <a href="https://gcms.labrulez.com/library?instrumentationItems=23&amp;search=hydrogen">hydrogen generator</a>. The generators come in different capacities depending on your requirements and have intrinsic safety features to limit hydrogen uses in cases of leaks or sudden pressure drops.
In addition all GC manufacturers have hydrogen sensors that can be fitted to the GC which will shutdown the instrument if an unexpected leak should occur.
<h3>Instrument Modifications</h3>
If there is currently a hydrogen supply to the instrument the process for the instrument is relatively simple. However before you proceed you may need to check the requirements from the manufacturers.
This is particularly applicable to thermal desorbers (TD) and detectors such as PDHID, TCD and ECD. The performance of a TD and these detectors can also be application dependent, however there are further modifications that can be made to minimise detrimental effects.
We would recommend a switching system (manual or automated) so you can switch between gases. This is a low cost and will enable the customer to maintain their existing analysis and develop and test/validate a new method without the possibility of instrument downtime and ingress of air.
After changing carrier gas you will need to change the EPC configuration on a modern instrument to the new carrier, so as the correct flows or pressures can be displayed.
<blockquote>
<h4>💡💡💡 <a href="https://gcms.labrulez.com/webinars?search=helium+to+hydrogen">Selection from dozens of Helium to Hydrogen in GC &amp; GC/MS webinars</a></h4>
</blockquote>
<blockquote>
<ul>
<li>Converting from Helium to Hydrogen Gas</li>
<li>Combating the Helium Shortage: Making the Switch from Helium to an Alternative Carrier Gas</li>
<li>Products &amp; Applications Series - Helium Part 2: Save it or Swap it!</li>
<li>From Helium to Hydrogen in GC-MS/MS</li>
<li>Choosing a different carrier gas in GC</li>
<li>Helium Shortage 4.0: Is hydrogen carrier gas the solution to the GC–MS problem?</li>
<li>Eliminating Dependency on Helium Supply for Your Thermal Desorption GC/MS Analysis</li>
<li>Alternative Carrier Gases for GC and GC-MS</li>
<li>Making the Switch from Helium to Hydrogen or Nitrogen Carrier Gas</li>
<li>Try Hydrogen and Nitrogen as Alternative Carrier Gases</li>
<li>Strategies to Mitigate for Rising Helium Gas Costs</li>
<li>Strategies to Save Helium and best practice for alternative GC carriers</li>
<li>Deliver more by using hydrogen carrier gas in thermal desorption-GC(MS) workflows</li>
<li>Using nitrogen as a GC-MS carrier gas: Opportunities to eliminate reliance on helium</li>
<li>Designed for Speed: A Fast-GC Forum</li>
<li>What’s Next After Helium? - Conserving or Switching Carrier Gas</li>
<li>Hydrogen as an alternative to Helium for GC</li>
</ul>
</blockquote>
<h3>Method Changes</h3>
Methods will need to be adapted or modified to the carrier gas changes. This would be mainly carrier gas and detector flow adjustments. However changes will be required to data handling parameters and realignment and recalibration of targeted and non targeted compounds.
<h3>Method Development/Validation</h3>
As the method parameters will need to change due to the new carrier gas, the analytical method will need to be revalidated. This will require parameters such as LOD’s, linear range, repeatability, accuracy, robustness and recovery and /or whatever the regulatory body or bespoke requirements are.
<h3>Knowledge to Change</h3>
Instrument configurations and applications are numerous, therefore whoever performs the conversions need to consider all of the issues and have a detailed knowledge of your existing and future measurements for a successful outcome.
<h3>Benefits of Hydrogen vs Helium</h3>
The benefits of using hydrogen are:
<ul>
<li>Readily available (on demand with generators)</li>
<li>Lower cost</li>
<li>Speed of analysis</li>
<li>Improved separation</li>
</ul>
Specific considerations are detailed below.
<h5>FID detector</h5>
<ul>
<li>Could operate with 2 gases (H₂ and Air)</li>
<li>Detector flows may have to be replumbed, adjusted and reoptimised and N₂ or air used as make up flow as an alternative.</li>
</ul>
<h5>MS (mass spectrometry) detector</h5>
<ul>
<li>May require less source cleaning</li>
<li>You might need to purchase a newer source that is more inert to limit fragmentation. Direct flows into the source maybe limited to &lt; 1.5ml/min. However there are work arounds to these issues.</li>
</ul>
<h5>TCD detector</h5>
<ul>
<li>As the detection method is based on thermal conductivity, carrier gas conversion requires more detailed application knowledge.</li>
</ul>
<h5>ECD detector</h5>
<ul>
<li>Make up gas would have to remain as nitrogen or Methane/Argon mixture for the detector to function.</li>
</ul>
<h5>PHDID detector</h5>
<ul>
<li>Will not function correctly with hydrogen carrier gas.</li>
</ul>
<h3>Conclusion</h3>
If these guidelines are considered, you will have the confidence to convert from helium to hydrogen carrier gas, thus increasing your sample throughput and reducing costs, while still providing accurate and reliable results that are fit for purpose.
<blockquote>
<h4>💡💡💡 <a href="https://gcms.labrulez.com/companies/171">ChromSolutions Ltd</a></h4>
</blockquote>
<blockquote>
What we offer at ChromSolutions is our wealth of experience in analytical instrument sales and support (over 110 years distributed through the members of our company). We can help you from defining your requirements to the implementation of a robust analytical method fit for purpose.
</blockquote>
<h3>Selection fro dozens of Helium to Hydrogen literature available <a href="https://gcms.labrulez.com/library?search=helium+to+hydrogen">in the LabRulezGCMS library</a></h3>
<ul>
<li>Hydrogen: A Superior Carrier Gas Alternative to Helium (Applications | 2009 | Merck)
</li>
<li>How to Combat the Helium Shortage: Making the Switch from Helium to Hydrogen or Nitrogen (Presentations | 2022 | Agilent Technologies)
</li>
<li>Addressing gas conservation challenges when using helium or hydrogen as GC carrier gas (Technical notes | 2022 | Thermo Fischer Scientific)
</li>
<li>Shimadzu’s Recommendations for Dealing with Current Helium Gas Shortag (Presentations | 2022 | Thermo Shimadzu)
</li>
<li>7 Steps to changing carrier gas from Helium to Hydrogen (Technical notes | 2016 | Peak Scientific)
</li>
<li>Ballooning helium costs keeping you up at night? Try Hydrogen and Nitrogen as Alternative Carrier Gases (Presentations | 2022 | Agilent Technologies)
</li>
<li>Countermeasures and Solutions for Helium Gas Supply Shortages - GCMS (Presentations | 2022 | Shimadzu)
</li>
<li>How to Combat the Helium Shortage: Making the Switch from Helium to Hydrogen or Nitrogen Carrier Gas (Presentations | 2019 | Agilent Technologies)
</li>
<li>FAMEs analysis method revalidation from helium to hydrogen for GC (Applications | 2015 | Peak Scientific)
</li>
<li>GC &amp; GC/MS Helium to Hydrogen Conversion Quick Reference Guide (Guides | 2022 | ChromSolutions)
</li>
<li>How to convert helium to hydrogen as a carrier gas in gas chromatography (Technical notes | 2013 | Parker Hannifin)
</li>
<li>The Effect of Draw-out Lens Diameter on Sensitivity of GC-MS analysis (Applications | N/A | Peak Scientific)
</li>
<li>From Helium to Hydrogen: GC-MS Case Study on SVOC’s in water (Presentations | N/A | Thermo Fischer Scientific)
</li>
<li>Conversion of GC/MS Methods From Helium To Hydrogen Carrier Gas (Posters | 2013 | Agilent Technologies)
</li>
<li>Helium What is the current cost to labs? (Technical notes | 2015 | Peak Scientific)
</li>
<li>Impact of GC Parameters on The SeparationPart 6: Choice of Carrier Gas and Linear Velocity (Guides | N/A | Restek)
</li>
<li>How to Convert from Helium to Hydrogen as a Carrier Gas in Gas Chromatography (Technical notes | 2012 | Parker Hannifin)
</li>
<li>Fast GC-MS Analysis of Semi-Volatile Organic Compounds: Migrating from Helium to Hydrogen as a Carrier Gas in US EPA Method 8270 (Applications | 2016 | Thermo Fischer Scientific)
</li>
<li>Benefits and Considerations of Converting to Hydrogen Carrier Gas (Technical notes | 2013 | Restek)
</li>
<li>Advantages and Disadvantages of Substitution of Helium as Carrier Gas in Gas Chromatography by Hydrogen. Part III. – Sample Introduction and Detectors (Scientific articles | 2013 | Kvasny Prumysl)
</li>
<li>The Use of Hydrogen Carrier Gas for GC/MS (Technical notes | 2012 | PerkinElmer)
</li>
<li>The Use of Alternative Carrier Gases in Gas Chromatography (Technical notes | N/A | SCION Instruments)
</li>
<li>Helium, Hydrogen, or Nitrogen—The Choice is Yours: Unique Rtx®-CLPesticides Column Set Provides Optimal Results for Organochlorine Pesticides GC-Micro-ECD Analysis Using Any Carrier Gas (Applications | 2014 | Restek)
</li>
<li>Advantages and Disadvantages of Substitution of Helium as Carrier Gas in Gas Chromatography by Hydrogen. Part I. – Technical and Safety Aspects (Scientific articles | 2013 | Kvasny Prumysl)
</li>
<li>Moving from Helium to Hydrogen as a Carrier Gas for the Thermo Scientific ISQ GC-MS System (Applications | 2012 | Thermo Fischer Scientic)
</li>
<li>Optimized PAH Analysis Using Triple Quadrupole GC/MS with Hydrogen Carrier (Applications | 2020 | Agilent Technologies)
</li>
</ul>

GC & GC/MS Helium to Hydrogen Conversion Quick Reference Guide

Natural gas has emerged as one of the most important energy sources in the world. Its abundant availability, low carbon emissions, and versatility have made it a preferred choice for a wide range of applications, including power generation, heating, and transportation. However, ensuring the safety, quality, and efficiency of natural gas requires accurate and reliable analysis. This is where natural gas analysers play a pivotal role.Natural gas analysers are advanced instruments designed to measure and analyse the composition and properties of natural gas. They provide valuable insights into key parameters such as the concentration of different gases, calorific value, impurities, and other relevant characteristics. This information is crucial for various stakeholders in the natural gas industry, including producers, distributors, regulators, and end-users.The primary function of a natural gas analyser is to determine the composition of the gas mixture. Natural gas is not a homogeneous substance; its composition varies from source to source and even within a single source. The major components of natural gas are methane (CH4), along with smaller amounts of ethane (C2H6), propane (C3H8), butane (C4H10), and traces of other hydrocarbons. Additionally, natural gas can contain impurities such as nitrogen (N2), carbon dioxide (CO2), hydrogen sulphide (H2S), and water vapor (H2O).Accurate measurement and monitoring of these components are critical for several reasons. First and foremost, the composition of natural gas affects its energy content and thus its value as a fuel. The calorific value, commonly expressed in British Thermal Units (BTU) per cubic foot or megajoules per cubic meter, indicates the heating capacity of the gas. This information is essential for determining pricing, evaluating the performance of gas-fired equipment, and ensuring compliance with regulatory standards. Moreover, the presence of impurities in natural gas can have significant consequences. For instance, high levels of CO2 can lower the energy content and increase the corrosion potential of the gas. H2S is a highly toxic gas that poses safety risks and can corrode pipelines and equipment. Therefore, accurate measurement and continuous monitoring of these impurities are vital for maintaining safety, protecting infrastructure, and complying with environmental regulations.Natural gas analysers employ various techniques to perform these measurements. The most commonly used methods include gas chromatography, infrared absorption, and mass spectrometry.<h5>Analyzer - Model Description / Published Method(s)</h5><ul><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.labrulez.com/labrulez-bucket-strapi-h3hsga3/NGAA_66dab6b6f7.pdf">Natural Gas A</a> - Single Channel Natural Gas Analyzer / ASTM D1945, GPA2261 (He/H2 not included)</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.labrulez.com/labrulez-bucket-strapi-h3hsga3/NGA_B_QRG_1_a6d11b801e.pdf">Natural Gas B</a> - Dual Channel Natural Gas Analyzer / ASTM D1945, GPA2261 (He/H2 not included)</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.labrulez.com/labrulez-bucket-strapi-h3hsga3/NGA_C_QRG_e66a58a952.pdf">Natural Gas C</a> - Extended Natural Gas Analyzer / GPA 2286 (He/H2 included)</li><li>Natural Gas D - Three Channel Bespoke Extended Natural Gas Analyzer / ASTM D1945, GPA2261, GPA 2286 (He/H2 included)</li></ul>Gas chromatography is particularly popular due to its high accuracy and versatility. It separates gas components based on their different affinities for a stationary phase, allowing for precise quantification.<h3>Hydrogen/Helium Separation</h3>These analysers are typically equipped with advanced sensors, detectors, and software algorithms to ensure accurate and reliable measurements. They are capable of operating in different gas streams, handling a wide range of pressures and temperatures, and providing real-time data. Analysers even offer remote monitoring and control capabilities, enabling operators to access and analyse data from anywhere, at any time.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chrom_Solutions_Hydrogen_Helium_Separation_ae018cb09f.jpg" alt="ChromSolutions: Hydrogen/Helium Separation" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chrom_Solutions_Hydrogen_Helium_Separation_ae018cb09f.jpg 245w," sizes="100vw" width="885" height="346">Natural gas analysers find applications across the entire natural gas value chain. During exploration and production, analysers help in assessing the composition and quality of natural gas reserves. In transmission and distribution, they ensure the proper functioning of gas pipelines and measure the gas quality at different stages. Gas utility companies utilize analysers to monitor the gas composition and ensure compliance with safety standards. Similarly, industrial users rely on analysers to optimize their processes and maintain the efficiency of gas-fired equipment.<h3>C1 - C15 Separation</h3><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chrom_Solutions_C1_C15_Separation_e47072962e.jpg" alt="ChromSolutions: C1 - C15 Separation" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chrom_Solutions_C1_C15_Separation_e47072962e.jpg 245w," sizes="100vw" width="916" height="363"><h3>Conclusion</h3>Natural gas analyzers are indispensable tools for the accurate and reliable determination of the components present and can provide other useful information such as corrosion issues and calorific values.<blockquote><h4>ChromSolutions Ltd</h4>Over 110 years of expertise in analytical instrumentation. Independent advice for analyser selection. Clear recommendations and comprehensive training. ChromSolutions offers reliable guidance and support for your analyser purchase, installation and operational journey.</blockquote>

Natural Gas Overview Quick Reference Guide

There are a number different Natural Gas Analysers, (NGAs) to meet the broadest range of stream sample types and throughput needs, whether the analysis is conducted in a lab, at-line or in the field. NGAs are standard ‘turnkey’ systems pre-configured and tuned at the factory to ensure their compliance with standard methods used to determine the heating value of natural gases and related streams.They can also be specially configured to determine other components of interest (e.g. sulphur compounds), to ensure the suitability for use in downstream processes. All systems employ a proven and optimized multi-channel/multi-dimensional approach to determine the heating/calorific value of natural gas, as well as quantify individual components.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_NGA_Basic_System_A_75d6252875.jpg" alt="Chromsolutions: NGA Basic (System A)" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_NGA_Basic_System_A_75d6252875.jpg 209w," sizes="100vw" width="659" height="493">The basic NGA (System A) is the simplest of all NGA analysers. The system employs:<ul><li>Single valve column designed for simplicity</li><li>Thermal Conductivity Detector (TCD)</li><li>Flame Ionization Detector (FID)</li></ul>The TCD is used for the determination of O2 , N2 , CH4 , CO2 and hydrocarbons, while the FID, connected in series, determines hydrocarbons in low concentrations, i.e. C3 - C5 and C6+ back-flushed grouping peak (late back-flush).A single unheated 4 port Liquid Sampling Valve (LSV) is available for LPG type samples.<h5>Analyser - Description / Published Method(s)</h5><ul><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGAA_66dab6b6f7.pdf">Natural Gas A</a> - Single Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_B_QRG_1_a6d11b801e.pdf">Natural Gas B</a> - Dual Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_C_QRG_e66a58a952.pdf">Natural Gas C</a> - Extended Natural Gas Analyser / GPA 2286 (He/H2 included)</li><li>Natural Gas D - Three Bespoke Extended Natural Gas Analyser / ASTM D1945, GPA2261, GPA 2286 (He/H2 included)</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_Natural_Gas_Sample_System_A_1_Air_2_Methane_3_Carbon_dioxide_4_Ethane_5_Hydrogen_Sulphide_6_Propane_7_i_Butane_8_n_Butane_9_i_Pentane_10_n_Pentane_e9bb9b64b9.jpg" alt="Chromsolutions: Natural Gas Sample - System A - 1. Air, 2. Methane, 3. Carbon dioxide, 4. Ethane, 5. Hydrogen Sulphide, 6. Propane, 7. i-Butane, 8. n-Butane, 9. i-Pentane, 10. n-Pentane" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_Natural_Gas_Sample_System_A_1_Air_2_Methane_3_Carbon_dioxide_4_Ethane_5_Hydrogen_Sulphide_6_Propane_7_i_Butane_8_n_Butane_9_i_Pentane_10_n_Pentane_e9bb9b64b9.jpg 245w," sizes="100vw" width="597" height="264"><h3>Conclusions</h3><h5>Natural Gas Analyser (System A)</h5><ul><li>The analysis is completely automated.</li><li>No costly method development.</li><li>A full range detection is possible.</li><li>All channel results are combined into 1 report.</li><li>The simple set-up is aimed easy operation/maintenance and service.</li></ul><blockquote><h4>ChromSolutions Ltd</h4>Over 110 years of expertise in analytical instrumentation. Independent advice for analyser selection. Clear recommendations and comprehensive training. ChromSolutions offers reliable guidance and support for your analyser purchase, installation and operational journey.</blockquote>

Natural Gas Analyser A - Quick Reference Guide

There are various Natural Gas Analysers (NGAs) available to cater to different sample types and throughput requirements, whether in a lab, at-line, or in the field. NGAs are pre-configured 'turnkey' systems designed to comply with standard methods for determining the heating value of natural gases and related streams.&nbsp;They can be customized to analyse additional components, such as sulphur compounds, ensuring suitability for downstream processes. These analysers utilize a proven multi-channel/multi-dimensional approach to determine the heating/calorific value of natural gas and quantify individual components.<figure class="image"><img style="aspect-ratio:638/410;" src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_NGA_Basic_System_B_b7c9a14277.jpg" alt="Chromsolutions: NGA Basic (System B)" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_NGA_Basic_System_B_b7c9a14277.jpg 243w," sizes="100vw" width="638" height="410"></figure>The NGA (System B) is a standard turnkey system designed for analysing natural gas and de-methaniser* hydrocarbon matrices. It accurately measures components of interest, such as oxygen, nitrogen, carbon dioxide, methane, ethane, propane, butane, iso-butane, pentane, hydrogen sulphide, and C6+ as a composite peak in natural gas. For de-methaniser streams, it analyses carbon dioxide, ethane, propane, butane, iso-pentane, hexane, and C7+ as a composite peak. In the gas method (2261), the composite peak includes hexane and heavier components (C6+), while in the liquid method (2177), it includes heptane and heavier components (C7+).*De-methaniser refers to the process of removing or reducing the methane component from a hydrocarbon mixture. It results in a product with higher concentrations of other hydrocarbon compounds, known as de-methaniser hydrocarbons or natural gas liquids (NGLs).<figure class="image"><img style="aspect-ratio:523/343;" src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_Natural_Gas_Sample_System_B_1_Oxygen_2_Nitrogen_3_Methane_4_C6_5_Nitrogen_6_Methane_7_C02_8_Ethane_9_H2_S_10_Propane_11_i_Butane_12_n_Butane_13_i_Pentane_6f4db607f5.jpg" alt="Chromsolutions: Natural Gas Sample - System B - 1. Oxygen, 2. Nitrogen, 3. Methane, 4. C6+, 5. Nitrogen, 6. Methane, 7. C02, 8. Ethane, 9. H2S, 10. Propane, 11. i-Butane, 12. n-Butane, 13. i-Pentane." srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_Natural_Gas_Sample_System_B_1_Oxygen_2_Nitrogen_3_Methane_4_C6_5_Nitrogen_6_Methane_7_C02_8_Ethane_9_H2_S_10_Propane_11_i_Butane_12_n_Butane_13_i_Pentane_6f4db607f5.jpg 238w," sizes="100vw" width="523" height="343"></figure><h5>Analyser - Description / Published Method(s)</h5><ul><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGAA_66dab6b6f7.pdf">Natural Gas A</a> - Single Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_B_QRG_1_a6d11b801e.pdf">Natural Gas B</a> - Dual Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_C_QRG_e66a58a952.pdf">Natural Gas C</a> - Extended Natural Gas Analyser / GPA 2286 (He/H2 included)</li><li>Natural Gas D - Three Bespoke Extended Natural Gas Analyser / ASTM D1945, GPA2261, GPA 2286 (He/H2 included)</li></ul><h3>Conclusions</h3><h5>Natural Gas Analyser (System B)</h5><ul><li>Fully automated analysis process.</li><li>No expensive method development required.</li><li>Capable of detecting a full range of components.</li><li>All channel results consolidated into a single report.</li><li>Simple setup for easy operation, maintenance, and service.</li></ul><blockquote><h4>ChromSolutions Ltd</h4>Over 110 years of expertise in analytical instrumentation. Independent advice for analyser selection. Clear recommendations and comprehensive training. ChromSolutions offers reliable guidance and support for your analyser purchase, installation and operational journey.</blockquote>

Natural Gas Analyser B - Quick Reference Guide

There are various Natural Gas Analysers (NGAs) available to cater to different sample types and throughput requirements, whether in a lab, at-line, or in the field. NGAs are pre-configured 'turnkey' systems designed to comply with standard methods for determining the heating value of natural gases and related streams.&nbsp;They can be customized to analyse additional components, such as sulphur compounds, ensuring suitability for downstream processes. These analysers utilize a proven multi-channel/multi-dimensional approach to determine the heating/calorific value of natural gas and quantify individual components.<figure class="image"><img style="aspect-ratio:456/367;" src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_NGA_Basic_System_C_c0d00676bd.jpg" alt="ChromSolutions: NGA Basic (System C)" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_NGA_Basic_System_C_c0d00676bd.jpg 194w," sizes="100vw" width="456" height="367"></figure>NGA (System C) - Extended Analysis is a specialized system designed for analysing "rich" natural gas or natural gas liquid streams. It offers the capability to separate and quantify hydrocarbon components up to C16. Similar to System B, it can also measure oxygen and nitrogen, while detecting hydrogen sulphide at a sensitivity of approximately 100 ppm. The system is equipped with a 14-port valve and a 6-port valve. The 14-port valve allows simultaneous introduction of the sample stream to three independent columns, enabling automated detector switching for high sensitivity detection of all components of interest.<figure class="image"><img style="aspect-ratio:377/283;" src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Chromsolutions_Natural_Gas_Sample_System_C_1_Propane_2_i_Butane_3_n_Butane_4_Neo_Pentane_5_Iso_Pentane_cefe75d793.jpg" alt="ChromSolutions: Natural Gas Sample - System C - 1. Propane, 2. i-Butane, 3. n-Butane, 4. Neo-Pentane, 5. Iso-Pentane, 6. n-Pentane, 7. Cyclopentane, 8. n-Hexane, 9. Methylcyclo-pentane, 10. Benzene, 11. Cyclohexane, 12. I2,2,4– Trimethylbenzene, 13. n-Heptane, 14. Toluene, 15. n-Octane, 16. Ethylbenzene, 17. M- +p-Xylene, 18. O-Xylene, 19. n-Nonane, 20. 1,2,4-Trimethylbenzene, 21. n-Decane" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Chromsolutions_Natural_Gas_Sample_System_C_1_Propane_2_i_Butane_3_n_Butane_4_Neo_Pentane_5_Iso_Pentane_cefe75d793.jpg 208w," sizes="100vw" width="377" height="283"></figure><h5>Analyser - Description / Published Method(s)</h5><ul><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGAA_66dab6b6f7.pdf">Natural Gas A</a> - Single Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_B_QRG_1_a6d11b801e.pdf">Natural Gas B</a> - Dual Channel Natural Gas Analyser / ASTM D1945, GPA2261</li><li><a target="_blank" rel="noopener noreferrer" href="https://gcms.cz/labrulez-bucket-strapi-h3hsga3/NGA_C_QRG_e66a58a952.pdf">Natural Gas C</a> - Extended Natural Gas Analyser / GPA 2286 (He/H2 included)</li><li>Natural Gas D - Three Bespoke Extended Natural Gas Analyser / ASTM D1945, GPA2261, GPA 2286 (He/H2 included)</li></ul><h3>Conclusions</h3><h5>Natural Gas Analyser (System C)</h5><ul><li>Fully automated analysis process.</li><li>No expensive method development required.</li><li>Capable of detecting a full range of components.</li><li>All channel results consolidated into a single report.</li><li>Simple setup for easy operation, maintenance, and service.</li></ul><blockquote><h4>ChromSolutions Ltd</h4>Over 110 years of expertise in analytical instrumentation. Independent advice for analyser selection. Clear recommendations and comprehensive training. ChromSolutions offers reliable guidance and support for your analyser purchase, installation and operational journey.</blockquote>

Natural Gas Analyser C - Quick Reference Guide
