EST Analytical CENTURION Water/Soil Purge and Trap Autosampler

The EST Analytical CENTURION delivers reliable purge and trap VOC analysis with high sample capacity, robust design, and intuitive software for water and soil testing.

The CENTURION is a flexible purge and trap autosampler available in two configurations: a combined water/soil system or a water-only system. Purge and trap technology enables the extraction of volatile organic compounds (VOCs) from samples by purging them with an inert gas onto a sorbent trap, where they are concentrated and subsequently transferred into instruments such as GC or GC/MS for precise analysis.Designed for laboratories worldwide, the CENTURION enhances throughput, ensures reliable performance, and simplifies VOC sample preparation. With robust engineering and intuitive software, it helps analysts and technicians maximize efficiency and maintain consistent results across demanding workflows.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/EST_Analytical_CENTURION_Water_Soil_Purge_and_Trap_Autosampler_3_3cb7b848e1.jpg" alt="EST Analytical: CENTURION Water/Soil Purge and Trap Autosampler" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_EST_Analytical_CENTURION_Water_Soil_Purge_and_Trap_Autosampler_3_3cb7b848e1.jpg 141w," sizes="100vw" width="704" height="778"><h4>Key Features</h4><h5>Reliable Purge &amp; Trap Performance</h5><ul><li>Proven XYZ autosampler design with heavy-duty rails for stability</li><li>Separate needles for water and soil samples to prevent cross-contamination</li><li>Internal standard addition with &lt;3% RSD precision</li><li>Engineered for consistent results right from the start</li></ul><h5>Optimized Productivity</h5><ul><li>Supports up to 100 water samples and 90 soil samples</li><li>Single calibration method accommodates both water and soil matrices</li><li>Integrated optical sensors reduce vial and syringe handling errors</li><li>Includes methanol extraction capability and optional pH detection</li></ul><h5>User-Friendly Operation</h5><ul><li>Unique software for prioritizing urgent/rush samples</li><li>400:1 dilution capability for flexible workflows</li><li>Intuitive control software accessible from any PC in the lab</li><li>Programmable soil needle depth to minimize clogging</li><li>Automated hot water rinse cycle to reduce carryover</li></ul><h4>Technical Specifications</h4><ul><li>Configurations: Water/Soil purge &amp; trap system or Water-only system</li><li>Sample Capacity: 100 water samples / 90 soil samples</li><li>Dilution Capability: Up to 400:1</li><li>Carryover Control: Programmable hot water rinse</li><li>Additional Functions: Methanol extraction, pH detection (optional)</li><li>Software: Intuitive, PC-based control with rush sample handling</li></ul>

EST Analytical EVOLUTION 2 Purge and Trap Concentrator

The EST Analytical EVOLUTION 2 concentrator delivers EPA-compliant VOC analysis with patented flow control, faster cycles, and compact, user-friendly design.

Developed with direct input from laboratory users, the EVOLUTION 2 purge and trap concentrator combines USEPA compliance with high productivity, stability, and simplified maintenance. Designed for reliable VOC concentration, it delivers superior performance and minimizes downtime, making it an ideal solution for today’s demanding laboratory environments.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/EST_Analytical_EVOLUTION_2_Purge_and_Trap_Concentrator_2_b841c750b8.jpg" alt="EST Analytical: EVOLUTION 2 Purge and Trap Concentrator" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_EST_Analytical_EVOLUTION_2_Purge_and_Trap_Concentrator_2_b841c750b8.jpg 129w," sizes="100vw" width="570" height="689"><h4>Key Features</h4><h5>Engineered for Accuracy</h5><ul><li>Unique 8-port valve pathway ensures advanced moisture control</li><li>Enhanced ventilation system shortens trap cool-down times</li><li>Patented Desorb Pressure Control (DPC) for improved chromatography results</li><li>Patented Desorb Flow Control (DFC) optimized for USEPA 524 methods</li></ul><h5>Maximized Productivity</h5><ul><li>Faster trap cooling reduces cycle times</li><li>Automated signaling boosts sample throughput</li><li>Innovative flow path design minimizes sample carryover</li><li>Proven Moisture Reduction Trap (MORT) technology</li><li>Dual-mode functionality for higher output and flexibility</li></ul><h5>User-Friendly Operation</h5><ul><li>Intuitive, advanced software interface</li><li>Quick-access design with removable covers for trap maintenance</li><li>Compact footprint saves valuable bench space</li></ul><h4>Technical Specifications</h4><ul><li>Compliance: USEPA 524 and related VOC methods</li><li>Sample Pathway: 8-port valve with advanced moisture control</li><li>Patented Features: DPC (Desorb Pressure Control), DFC (Desorb Flow Control), MORT (Moisture Reduction Trap)</li><li>Productivity: Dual-mode operation, automated cycle optimization</li><li>Design: Compact footprint, easy maintenance access</li></ul>

EST Analytical AS120 Autosampler

The AS120 GC Autosampler boosts productivity with dual-injector support, 120/200 vial capacity, programmable injections, and seamless GC/GC-MS integration.

The AS120 Autosampler is a cost-effective, fully electric XYZ sampler for GC and GC/MS applications. Driven by stepper motor technology, it combines modern engineering with user-friendly operation, meeting both routine and advanced analytical needs. With high-capacity sample trays, flexible injection modes, and reliable performance, the AS120 ensures laboratories can boost productivity while maintaining precise, consistent results.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/EST_Analytical_AS_120_Autosampler_7cc5a79884.jpg" alt="EST Analytical: AS120 Autosampler" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_EST_Analytical_AS_120_Autosampler_7cc5a79884.jpg 203w," sizes="100vw" width="1056" height="812"><h4>Key Features</h4><h5>Maximum Productivity</h5><ul><li>Dual-injector capability for maximum GC throughput</li><li>Automated injector alignment—no manual adjustments required</li><li>Variable injection rate tailored to injector type and analytical method</li><li>Choice of 120- or 200-position sample trays, easily removable for quick loading</li></ul><h5>Durable, Flexible Engineering</h5><ul><li>Robust XYZ syringe mechanism accesses vials, solvents, and standards with precision</li><li>Adjustable parameters: injection volume, speed, dwell times, and solvent flush options</li><li>Supports multiple methods per sequence and dual-column operation</li><li>Fully programmable via intuitive keypad interface</li></ul><h5>Hassle-Free Operation</h5><ul><li>Compatible with screw-cap and crimp-top septum vials</li><li>Simple GC integration with standard remote I/O signals and RS-232 communication</li><li>Quick mounting with keypad-based syringe/injector alignment</li><li>Priority manual sample feature enables urgent “RUSH” sample handling</li></ul><h4>Technical Specifications</h4><ul><li>Drive: All-electric, stepper motor XYZ system</li><li>Capacity: 120 or 200 vial tray options</li><li>Compatibility: GC and GC/MS systems with standard I/O and RS-232 interface</li><li>Injection Modes: Variable rate, programmable volume, dual-injector support</li><li>Control: Keypad-driven menu with multiple method programming</li><li>Sample Handling: Screw-cap or crimp-top septum vials</li></ul>

EST Analytical FLEX 2 Robotic Sampling Platform

The FLEX 2 autosampler streamlines GC/GC-MS workflows with liquid, headspace, and SPME capability, MTX tool change, and Prep Ahead for faster, more reliable VOC analysis.

The FLEX 2 is a versatile GC autosampler designed to handle both sample preparation and sample introduction for GC and GC/MS analysis. Supporting liquid injection, headspace, and SPME, it delivers exceptional accuracy and reproducibility. Its Prep Ahead function improves efficiency by allowing sample preparation during ongoing GC runs, maximizing system utilization and throughput.<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/EST_Analytical_FLEX_2_Robotic_Sampling_Platform_3_853e02f151.jpg" alt="EST Analytical: FLEX 2 Robotic Sampling Platform" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_EST_Analytical_FLEX_2_Robotic_Sampling_Platform_3_853e02f151.jpg 168w," sizes="100vw" width="628" height="584"><h4>Key Features</h4><h5>Flexible Sample Preparation with Multi Tool Change (MTX)</h5><ul><li>Automated Multi Tool Change (MTX) enables seamless switching between tools</li><li>Enhances laboratory productivity, accuracy, and safety by reducing manual prep errors</li><li>Supports dilution, reagent addition, and internal standard spiking with precision</li><li>Can operate as a benchtop preparation station for derivatization and extraction steps</li></ul><h5>Liquid Injection Capabilities</h5><ul><li>Injection range: 0.5–10 μL (standard syringe) or 50–500 μL (optional large-volume syringe)</li><li>Supports both standard and large-volume injections (up to 500 μL)</li><li>Programmable injection speed control, from ultra-fast to very slow</li><li>Optional cooled trays available for temperature-sensitive samples</li></ul><h5>Headspace Sampling</h5><ul><li>Injection range: 100–2500 μL (2.5 mL syringe), 100–1000 μL (1.0 mL syringe), or 500–5000 μL (5.0 mL syringe)</li><li>Offers both orbital and oscillating agitation to improve sample consistency</li><li>Six heated vial positions for 2, 10, or 20 mL vials</li><li>Temperature range: ambient to 200 °C</li><li>Shaking: orbital (120–750 rpm) or oscillation (190 Hz)</li></ul><h5>Automated SPME</h5><ul><li>Compatible with both traditional and direct immersion SPME methods</li><li>Heated conditioning station:<ul><li>Fiber: ambient to 350 °C</li><li>Needle: ambient to 150 °C</li><li>Sweep gas port for conditioning</li></ul></li><li>Heated mixing station: ambient to 150 °C, mixing speeds 380–725 rpm</li></ul><h5>Efficiency &amp; Throughput</h5><ul><li>Prep Ahead function allows ongoing sample prep during GC runs</li><li>Fully automates switching between liquid injection, headspace, and SPME with MTX</li><li>Reduces manual workload and preparation errors while improving reproducibility</li></ul><h4>Technical Specifications</h4><ul><li>Compatible Systems: GC and GC/MS platforms</li><li>Injection Modes: Liquid (0.5–500 μL), Headspace (100–5000 μL), SPME (traditional &amp; direct immersion)</li><li>Temperature Ranges: Headspace up to 200 °C, SPME fiber up to 350 °C, SPME needle up to 150 °C</li><li>Agitation: Orbital (120–750 rpm) and oscillating (190 Hz)</li><li>Capacity: Six heated vial positions for 2, 10, or 20 mL vials</li><li>Automation: Multi Tool Change (MTX), Prep Ahead function</li></ul>

EST Analytical LGX-50 for Methane in Water

The EST LGX-50 automates RSK-175 dissolved gas testing in water, boosting throughput, ensuring ASTM/EPA compliance, and reducing manual sample preparation errors.

The LGX-50 automates the preparation of water samples for headspace analysis of dissolved gases such as methane, ethane, and ethene. Traditionally, RSK-175 testing has been labor-intensive and time-consuming, requiring manual vial preparation. The LGX-50 eliminates this step, streamlining workflows and ensuring compliance with EPA Method 5035 and ASTM D8028. By automating dissolved gas extraction, laboratories can boost throughput, reduce errors, and deliver more consistent results for shale gas and environmental testing.<h4>Key Features</h4><h5>Maximized Productivity</h5><ul><li>Fully automates RSK-175 sample processing</li><li>ASTM D8028 compliant for dissolved gas testing</li><li>Holds up to 50 samples for high-throughput operation</li><li>Optical sensors prevent vial misplacement and syringe/elevator errors</li><li>Robust XYZ design ensures reliability and consistent performance</li></ul><h5>Simplified Operation</h5><ul><li>Intuitive, user-friendly software designed for quick setup and operation</li><li>Remote access functionality allows labs to monitor sample progress via the server</li><li>Reduces manual preparation steps, increasing accuracy and reproducibility</li></ul><h4>Technical Specifications</h4><ul><li>Compliance: EPA Method 5035, ASTM D8028</li><li>Capacity: Up to 50 samples per batch</li><li>Target Compounds: Methane, ethane, ethene, and other dissolved gases in water</li><li>Automation: XYZ robotic design with optical sensors for error prevention</li><li>Software: Intuitive, remote-access capable interface</li></ul>

Products from EST Analytical distributed by EST Analytical - page 1
